D-Link DIS-2650AP
Industrial AC1200 Wave 2 Access Point content_copy

The DIS-2650AP Industrial AC1200 Wave 2 Access Point is specifically designed to operate in harsh environments with a wide operating temperature range and over-voltage and ESD protection. The access point has a robust metal housing and is suitable for DIN rail or wall mounting - ideal for industrial installations.

Highlights

• Dual-band AC1200 speed: 300 Mbps on 2.4 GHz, 867 Mbps on 5 GHz
• Wide operating temperature range of -20 to 65 degrees C
• Built-in 2 kV surge protection and 15 kV ESD protection
• Power supply 12 up to 48 V DC terminal block dual input or 802.3at Power over Ethernet
• 2 x Gigabit LAN port (802.3at Power over Ethernet) and console port
• Two external omnidirectional antennas
• Wall and DIN rail mounting possible

Product type

• Access point
• ear category (ElektroG) : relevant, Category 6: small devices for IT and telecommunications technology, small devices for IT and telecommunications technology B2C

Specifications

• Operating temperature max: 65 °C
• Operating temperature min: -20 °C
• Area of application: Indoor

Shipping

• WEEE: 10490255

Power supply

• PoE standard: PoE+ - 802.3at

Antenna

• Antenna technology: omnidirectional
• Reception standard: WLAN
• Gain: 3 dbi

Data transmission

• WLAN standard: IEEE 802.11a - WiFi 2, IEEE 802.11b - WiFi 1, IEEE 802.11g - WiFi 3, IEEE 802.11n - WiFi 4, IEEE 802.11ac - WiFi 5

Basic features

• Color: Black
• Height: 40 mm
• Length/Depth: 105.9 mm
• Width: 196.2 mm
• Weight: 785 g

Scope of delivery

• D-Link DIS-2650AP Industrial AC1200 Wave 2 Access Point

Antenna
Antenna type	External
Antenna direction type	Omni-directional
Antennas quantity	2
Antenna gain level (max)	3 dBi
Certificates
Certification	FCC, CE, LVD
Design
Placement	Wall
Product colour	Black
Features
Maximum data transfer rate	1200 Mbit/s
Maximum data transfer rate (2.4 GHz)	300 Mbit/s
Maximum data transfer rate (5 GHz)	866 Mbit/s
Ethernet LAN data rates	10,100,1000 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u
2.4 GHz
5 GHz
Logistics data
Harmonized System (HS) code	85176990
Management features
Web-based management
Operational conditions
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	-20 - 65 °C
Storage temperature (T-T)	-40 - 80 °C
Storage relative humidity (H-H)	5 - 95%
Packaging content
Quantity per pack	1 pc(s)
Ports & interfaces
Ethernet LAN (RJ-45) ports	2
Power
Power consumption (max)	14.478 W
Power over Ethernet (PoE)
Security
Security algorithms	64-bit WEP, 128-bit WEP, SSID, SSL/TLS, WPA, WPA2
Weight & dimensions
Width	196.2 mm
Depth	105.9 mm
Height	40 mm
Weight	785 g

---
