Chauvin Arnoux P01140822 CA 6522 insulation meter
|
596,48 EUR |
|
|
( 709,81 EUR incl. VAT ) plus delivery charges |
|
| Delivery time from supplier's stock (ca.) 0 workdaysinfo_outline | |
| Lieske Part No.: | 1927836 |
|---|---|
| Mfg Part No: | P01140822 |
| Weight: | 0.12 kg |
Product information for Chauvin Arnoux P01140822:
Highlights:
• Digital insulation and continuity tester for insulation resistance measurements up to 40 GΩ
• Ideal for industrial preventive maintenance to detect insulation damage and aging
• Large illuminated display with dual 4000-digit readout + logarithmic bargraph
• 3 test voltages (250 V / 500 V / 1000 V) for various applications
• Standards-compliant continuity testing with 200 mA test current and lead compensation for improved accuracy
• 3 measurement modes: Manual, continuous, or timed
• Multimeter function: Voltage (TRMS & DC)
Description:
Insulation and Continuity Tester up to 1 kV Test Voltage
The C.A 652x and C.A 653x series models are compact, lightweight, and user-friendly insulation testers, perfect for industrial maintenance and precise diagnostics.
Ergonomics and User Convenience:
- Rugged housing compliant with 600 V CAT IV, IP54/IK04 protection
- Magnetic fold-out stand for hands-free use on steel surfaces
- Large illuminated dual digital display with logarithmic bargraph
- Remote probe with built-in light for working in dark environments
Functions:
- Insulation Testing: Test voltages from 250 V to 1000 V, measuring range up to 40 GΩ
- Continuity Testing: 200 mA test current per IEC 61557, voltage protection circuit
- Multimeter Function: Voltage measurement up to 700 V, frequencies up to 800 Hz, resistances up to 999 kΩ, capacitances up to 10 µF
- Customizable Measurements: Two fixed and one adjustable alarm thresholds, ΔREL function for deviation display
Storage and Analysis:
- 300 internal memory slots (1300 for Bluetooth models)
- Megohmmeter Transfer (MEG) software for PC integration, real-time graphs, and data transfer
- Optional DataView® software for creating test reports
Technical Data:
- Test Voltages: 250 / 500 / 1000 V
- Insulation Resistance Range: Up to 40 GΩ
- Test Modes: Manual, locked, timer
- Voltage Measurement: Up to 700 V TRMS/DC
- Continuity Testing: 200 mA test current
- Display: Dual digital display and logarithmic bargraph
- Power Supply: 6 x LR6/AA batteries
- Dimensions: 211 x 108 x 60 mm
- Weight: 850 g
- Protection Rating: IP54, measurement category 600 V CAT IV
