Chauvin Arnoux MTX1054-PC MTX 1054 - Dig. Oscilloscope "@ Scope in box" - 4x150MHz, Ethernet, SPO (discontinued model)
|
1.237,96 EUR |
|||||||||||
|
( 1.473,17 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time from supplier's stock (ca.) 5 workdaysinfo_outline | |||||||||||
| Lieske Part No.: | 838279 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | MTX1054-PC | ||||||||||
| Weight: | 0.2 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Chauvin Arnoux MTX1054-PC:
Highlights:
• Spectrum analyzer for versatile frequencies from 400 kHz to 1 GHz
• Suitable for EMC pre-compliance testing
• Direct PC connection via USB
• Horizontal display of up to 5000 points on the PC screen
• Report creation, screenshots, data export to Excel, etc.
• Q-Peak detection with near-field probes (HX0082) possible to simplify EMC pre-compliance tests
Description:
The MTX 1050 is a compact and economical spectrum analyzer designed for versatile use in small and medium-sized enterprises as well as for technical training at engineering schools and vocational institutions. This blind" device displays its measurement results directly on a PC screen and is lightweight and portable. With a frequency range of 400 kHz to 1 GHz, it supports flexible applications, while the high frequency stability of ±5 ppm/year ensures precise measurements. The analyzer provides a measurement dynamic range from -90 dBm to +20 dBm and features six sampling speeds, along with three analysis and video filters. The PC-controlled display can show up to 5000 horizontal points, allowing detailed analysis. The software offers comprehensive support with functions such as report creation, screenshots, and data export to Excel. Q-Peak detection, especially when combined with near-field probes HX0082 and HX0083, facilitates EMC pre-compliance testing. The MTX 1050 is user-friendly with its "Plug & Play USB connection and multilingual PC software.
Technical Details:
- Type: Spectrum analyzer
- Frequency range: 400 kHz to 1 GHz
- Compatibility: PC software for Windows
- Connection: USB (“Plug & Play”)
- Display: PC-controlled, color display with up to 5000 points horizontal resolution
- Measurement range: -90 dBm to +20 dBm
- Frequency stability: ±5 ppm/year
- Sampling speeds: 6
- Analysis filters: 3
- Video filters: 3
- Functions: EMC pre-compliance, FM demodulation, Q-Peak detection (with HX0082), data export
- Supported formats: Screenshots, Excel data export
Included Items:
- MTX 1050 spectrum analyzer
- USB connection cable
- Multilingual PC software
- Documentation
