Canon PIXMA Pro-200S A3+ printer content_copy

The Canon PIXMA PRO-200S is an inkjet printer specifically developed for professional and high-quality photo printing. It features an 8-color inkjet system with ChromaLife 100+ inks, ensuring vibrant colors, high color accuracy, and long-lasting print results. The printer is designed for use in home and office environments and offers a maximum print resolution of 4800 x 2400 DPI, which is particularly beneficial for detailed and sharp photo prints. The printing technology enables borderless printing in formats up to A3+, allowing images to be output without white borders.

Applications
This printer is especially suitable for photographers requiring high-quality prints in various formats, as well as users creating professional photo prints for presentations, galleries, or personal use. Support for various paper types, including photo paper, Fine Art paper, canvas, and transfer paper, expands its application possibilities. The maximum paper size is A3+ in the Top-Tray and Manual Feed, with custom formats up to a length of 990.6 mm also printable.

Functions and Equipment in Detail
The printer features an integrated 3-inch LCD display with touch control, enabling access to print settings, ink level indicators, and maintenance functions. This makes operation intuitive and simplifies daily use. Paper handling includes three different feed options: Top-Tray, Manual Feed, and Multi-Purpose Tray, supporting a wide range of media formats and types. Automatic paper alignment corrects potential misalignments to prevent printing errors.

Technology Explained Simply
The printing technology is based on an inkjet system with a total of 6,144 nozzles, where each of the eight colors (Black, Cyan, Magenta, Yellow, Photo Cyan, Photo Magenta, Gray, Light Gray) has 768 nozzles. The inks are dye-based and provide high color brilliance and good lightfastness. The maximum print resolution of 4800 x 2400 DPI ensures high detail accuracy, especially for photo prints. Print speed is approximately 1.5 minutes per page for color printing (27,9 cm ( 11 inch ) x 35,6 cm ( 14 inch ) on A3+ with borderless printing) and about 2.83 minutes per page for black and white printing.

Compatibility and Accessories
The printer is compatible with various operating systems, including Windows 10, 11, 8.1, as well as Mac OS X from version 10.15 Catalina to 14.0 Sonoma. ChromeOS is also supported. Network functions include WLAN (standards 802.11a/b/g/n, Wi-Fi 4), Ethernet/LAN, and mobile printing technologies such as Apple AirPrint, Mopria Print Service, and PIXMA Cloud Link. Connections include USB and PictBridge, enabling direct connection to cameras. Print settings can be controlled via the Canon PPL software (Professional Print & Layout), which allows seamless editing and print processing from photo editing programs.

Installation and Mounting
Installation is performed using the supplied software, which can be downloaded from the official manufacturer websites. Setup is done via USB, LAN, or WLAN. Operation is performed via the integrated touch display, making additional control aids unnecessary. Paper tray configuration is flexible, with the Top-Tray capable of holding up to 100 sheets of paper. Settings for paper type, format, and print quality can be adjusted directly on the device.

Advantages in Operation
The printer offers high print quality for photo prints, supports a wide range of paper types and formats, and enables flexible operation via various interfaces. The integrated PPL software solution allows an efficient workflow from image editing to printing. Power supply is via AC mains voltage (100–240 V, 50/60 Hz), with an average power consumption of 17 W during printing. In standby mode, consumption is 2.3 W, and in the off state, it is 0.05 W. The product color is Black, dimensions are 639 mm (width) x 379 mm (depth) x 200 mm (height), and weight is 14.1 kg. The printing technology is designed for indoor use, with print quality remaining stable even during extended printing sessions. Ink cartridges are available in type CLI-65, with all colors being dye-based.

Features
Market positioning	Home & office
Product colour	Black
Printing colours	Black, Cyan, Grey, Light grey, Magenta, Photo cyan, Photo magenta, Yellow
Display	LCD
Display diagonal	7.62 cm (3")
Control type	Touch
Built-in display
Network
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Mobile printing technologies	Apple AirPrint, Mopria Print Service, PIXMA Cloud Link
Wi-Fi
Ethernet LAN
Bluetooth
Paper handling
Paper tray media types	Photo paper, Plain paper
Maximum ISO A-series paper size	A3+
ISO A-series sizes (A0...A9)	A3, A3+, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Envelopes sizes	Com-10, DL
Borderless printing media sizes	4x6, 5x7, 7x10, 8x10, A3, A3+, A4
Photo paper sizes (imperial)	4x6,5x7,7x10,8x10,10x12,11x14,12x12
Ports & interfaces
PictBridge
USB port
Power
Power source	AC
Power consumption (printing)	17 W
Power consumption (standby)	2.3 W
Power consumption (off)	0.05 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Printing
Print technology	Inkjet
Maximum resolution	4800 x 2400 DPI
Borderless printing
System requirements
Windows operating systems supported	Windows 10, Windows 11, Windows 8.1
Mac operating systems supported	Mac OS X 10.15 Catalina, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma
Other operating systems supported	ChromeOS
Weight & dimensions
Width	639 mm
Depth	379 mm
Height	200 mm
Weight	14.1 kg

---
