Busch Jaeger 2CKA006590A0192 6586/14 Busch-Dimmer grey conventional
|
340,10 EUR 354,42 EUR |
|||||||||||
|
( 404,72 EUR incl. VAT ) ≈ £284.66 | ≈ $380.57 plus delivery charges: 55,00 € |
|||||||||||
| Delivery time from supplier's stock (ca.) 5 workdaysinfo_outline | |||||||||||
| In Stock: >10 pieces | |||||||||||
| Lieske Part No.: | 1349110 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 2CKA006590A0192 | ||||||||||
| UPC/EAN: | 4011395251768 | ||||||||||
| Weight: | 0.1428 kg | ||||||||||
| Type: | 6586/14 | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Busch Jaeger 2CKA006590A0192:
Optimized for dimming retrofit LED lamps (LEDi).
For dimmable retrofit LED lamps (LEDi). For dimmable retrofit LED lamps (LEDi) on conventional or electronic transformers. For
incandescent lamps, 230 V halogen lamps, low-voltage halogen lamps with conventional or electronic transformers and dimmable halogen energy-saving lamps.
Mixed load operation of LEDi and conventional lamps possible.
With memory, snooze, wake-up, children's room, central off, cleaning light and time function.
For staircase light controls with automatic switch-off and warning function in accordance with DIN 18015-2.
Supports compliance with the Energy Saving Ordinance (EnEV 2014).
Low noise through the use of MOSFET transistors.
Short-circuit proof and overload-proof (electronic fuse).
With manually adjustable operating mode: leading edge / trailing edge.
With adjustable minimum / maximum brightness.
With light value storage. Operation also possible via conventional buttons (2020 US, 2021/6 UK).
Illumination of the extension button only possible with N-conductor connection.
Extension input for short switching pulses (button) and permanent contact (switch/timer).
Extension input designed as a wide voltage input (8-230 V AC/DC) galvanically isolated.
Nominal voltage: 110 - 230 V, +10 % / -10%
Nominal frequency: 50 Hz/60 Hz
Nominal power: 20 - 300 W/VA (phase control in 230 V~ networks)
Nominal power: 40 - 800 W/VA (phase control in 230 V~ networks)
Nominal power: 20 - 150 W/VA (phase control in 110/127 V~ networks)
Nominal power: 40 - 400 W/VA (phase control in 110/127 V~ networks)
| General | |
| Assembly arrangement | Basic element |
| Number of modules (module system) | 4 |
| Type of load | Universal and LED Retrofit |
| Mounting method | Other |
| Type of fastening | Snapper mounting |
| Material | Plastic |
| Material quality | Thermoplastic |
| Surface protection | Untreated |
| Surface finishing | Matt |
| Colour | Grey |
| RAL-number (akin) | 7035 |
| Suitable for degree of protection (IP) | IP20 |
| Impact strength | IK00 |
| Nominal voltage | 230 |
| Control voltage | 230 |
| Width of device | 85 |
| Height of device | 74 |
| Depth of device | 72 |
| Halogen free | |
| IFTTT support available | |
Questions & answers
What is the delivery time of Busch Jaeger 2CKA006590A0192 6586/14 Busch-Dimmer grey conventional?
The article Busch Jaeger 2CKA006590A0192 6586/14 Busch-Dimmer grey conventional is currently in stock
According to our experience the article is ready for dispatch within 5 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Busch Jaeger 2CKA006590A0192 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Busch Jaeger 2CKA006590A0192 6586/14 Busch-Dimmer grey conventional always at the best possible price. We can give you a discount of 2% on Busch Jaeger 2CKA006590A0192 6586/14 Busch-Dimmer grey conventional if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 4 pieces of Busch Jaeger 2CKA006590A0192 6586/14 Busch-Dimmer grey conventional we can offer you a price of 329,90 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
