BlackBox VX-HDMI-4KIP-RX MEDIACENTO IPX 4K RECEIVER - HDMI, USB, SERIAL, IR, AUDIO

HDMI-over-IP Extender – MediaCento IPX 4K, USB Audio Serial IR

The MediaCento IPX 4K HDMI-over-IP Extender allows for flexible 4K UHD HDMI signal distribution and extension over a Gigabit network. This system is ideal for various AV setups, such as connecting one source to one display, one source to multiple displays, or creating an 8x8 video wall configuration. With 4K resolution support up to 4096 x 2160 at 30 Hz and 1080p at 60 Hz, high-quality images are displayed with virtually no delay in under one frame (<1 Frame or <33 ms).

Featuring USB 2.0 control, bidirectional IR, and RS-232 ports, this system offers easy and flexible control. Additionally, with PoE support, the need for external power at the display is eliminated, reducing cable clutter. Its scalable structure allows for easy addition of more displays or sources through the network switch, making it a future-proof solution for digital signage and video walls.

MediaCento IPX 4K is compatible with touchscreens and KVM consoles and is ideal for professional applications in hospitality, retail, command centers, classrooms, and various other environments. The optional MediaCento Controller enables centralized management and settings for video wall and matrix configurations.

Technical Data:

Resolution:

• Up to 4K UHD 4096 x 2160 @ 30 Hz, 1080p @ 60 Hz
• Supports all 3D formats

Distance:

• CATx: 100 m
• Single-mode fiber (SFP): Up to 30 km (depending on SFP module)

Latency:

• 4K @ 30 Hz: < 1 Frame (33 ms or less)
• 1080p @ 60 Hz: 17 ms

Control:

• USB 2.0, bidirectional infrared, and RS-232
• User control via push buttons: Set/Reset, Function, Video Channel

Connections:

Transmitter:

• HDMI F-video input
• DB9 male for serial RS-232 control port
• RJ-45 network
• 2x 3.5 mm audio jacks
• SFP slot for fiber optics
• 4x USB Type A
• 2x 3.5 mm (IR)

Receiver:

• 2x HDMI F video outputs, 1x HDMI F video input
• DB9 female for serial RS-232 control port
• RJ-45 network
• 2x 3.5 mm audio jacks
• SFP slot for fiber optics
• 1x USB Type B jack

PoE:

• IEEE 802.3at compliant; operating at 48 VDC, input range: 36 to 57 VDC
• Consumption: 10.5 W

Power Supply:

• 1x 5 VDC, 3 A power adapter

Environmental Conditions:

• Operating temperature: 0 to 50 °C
• Storage temperature: -20 to +60 °C

Indicators:

• LEDs for power, link, function, EDID, SFP, video profile selection

Dimensions and Weight:

• Per unit: 3.2 x 9.8 x 18 cm
• Weight: 0.45 kg per unit

TAA Compliant: Yes

Warranty:

• 3 years Double Diamond™ (standard)
