BlackBox VX-1001-TX VX1000 HDMI AND USB TRANSMITTER

4K HDMI CATx Extender USB - VX1000 Series

Extend HDMI audio and video signals, Ethernet, RS-232, and USB over CATx cable up to 100 m, ensuring a reliable connection with superior video quality.

Supports up to 4K (UHD) resolution.
True 48V PoC powering requires only one power source for transmitter and receiver.
USB support for keyboard and mouse applications.
Automatic HDMI EDID management for simplified setup.
HDCP 2.2 compliant for content protection.
RS-232 and Ethernet pass-through for control and networking functions.
All ports are conveniently located on one side of the device for easy installation.
Compatible with 4 x 1 and 8 x 2 presentation switchers (AVSC-0401H-R2, AVSC-0802H).

Specifications:

Approvals:

• CE, FCC, RoHS

Video:

• Input:
- VW-1001-RX: 1 x CATx
- VW-1001-TX: 1 x HDMI IN, HDMI 1.4 with HDCP 2.2

• Output:
- VW-1001-RX: 1 x HDMI OUT, HDMI 1.4 with HDCP 2.2
- VW-1001-TX: 1 x CATx OUT

• Supported Resolutions: 480i, 480p, 576i, 576p, 720P, 1080i, 1080p, 3840 x 2160 at 24/25/30/50/60 Hz
• Maximum Pixel Clock Rate: 297 MHz
• Video Impedance: 100 Ω

Audio:

• Supported Audio Formats: Stereo, LPCM 5.1, LPCM 7.1; Dolby True HD, DTS-HD Master Audio

Control and Connectivity:

• 1 x RS-232, 1 x Ethernet, 2 x USB-A ports

Power and Protection:

• ESD Protection: ±8 kV (Air Discharge), ±4 kV (Contact Discharge)
• Surge Protection: ±1 kV
• Electrical Burst Protection: 1 kV (Data Cable), 2 kV (Power Cable)
• Power Supply: DC12V/1.5 A
• Power Consumption: 1080p at 60 Hz: max 13.08 W (pair); 4K at 60 Hz: max 13.2 W (pair)

Physical Properties:

• Dimensions: 2.5 H x 22 W x 9.32 D cm
• Weight: 0.5 kg

Environmental:

• Operating Temperature: 0 °C to 45 °C
• Storage Temperature: -20 °C to 70 °C
• Humidity: 10 % to 90 %, non-condensing
