BlackBox SS8P-SH-DP-U SECURE KVM SWITCH, SH, 8-PORT, DP, USB

Secure KVM-Switch, NIAP 3.0, 4K DisplayPort Single-Head

Control up to four computers from a single user console, maintaining complete data security across systems. This NIAP 3.0-certified KVM switch offers secure access to multiple computers on separate networks, protecting sensitive data.

- Secure access to computers across different networks
- Protects against unauthorized access and accidental data transfer
- Ideal for organizations handling sensitive data at multiple security levels
- Certified to NIAP Protection Profile Version 3.0
- OS Compatibility: Windows, Mac, and Linux
- 4K Ultra-HD DisplayPort (3840 x 2160 at 30 Hz)
- Secure EDID learning and emulation for broad monitor compatibility
- Balanced speaker outputs with audio switching
- Locking power supply
- Advanced, configurable CAC port for specific peripheral assignment
- TEMPEST options available; contact sales for details
- Warranty: 3-Year Double Diamond™

Key Security Features:

• Port Isolation: Prevents data exchange between secure and external ports
• Mechanical, electrical, and optical isolation prevent hacking and data leakage
• Protected firmware prevents unauthorized reprogramming or access
• Automatic cache clearing before each switch
• Tamper-proof housing with intrusion detection

Black Box's NIAP PP3.0-certified secure KVM switches provide a protected desktop access solution, safeguarding against cyberattacks for government, finance, healthcare, traffic control, and educational institutions. Black Box secure KVM switches offer seamless switching between up to 16 computers, servers, or thin clients with Windows or Linux OS.

Comprehensive Portfolio of Secure KVM Switches:

- Available with 2, 4, 8, or 16 computer ports
- Digital and analog 4K video options for consoles with up to four monitors
- Matrix switches for up to 4 users and single-user models
- KM switches with specialized computer-monitor connections and mouse switching
- 4-Port DVI switch with full-screen and 4-in-1 window display
- 1-Port KVM protector for isolated systems

Secure KVM Switches for Single User Console with DisplayPort Video:

These KVM switches support a user console with DisplayPort monitor (or HDMI with adapter), USB keyboard and mouse, audio, and optional CAC support. Models are available with two, four, or eight ports and feature front-panel buttons with LED indicators for secure and easy switching.

Reasons for Secure KVM Switches:

Connecting peripherals like keyboard and speakers to a PC poses data leak and hacking risks. Standard KVM switches lack filters for data detection and protection between PC and peripherals.

Certified to the Latest NIAP PP3.0 Security Profile:

Designed for defense and intelligence applications, Black Box secure KVM switches are NIAP PP 3.0-certified, meeting the highest standards of information security. The switches prevent data leakage between PCs and peripherals with unique hardware configurations, eliminating potential cyber threats.

Technical Specifications:

• Certifications: CE, RoHS, UL, TAA-compliant
• Video Formats: DisplayPort 1.2
• Max Resolution: 4K UHD 3840 x 2160 at 30 Hz
• Max Pixel Clock: 248 MHz
• DDC: 5 Volt p-p (TTL)
• Data Rate: 1.65 Gbps
• Input EQ: automatic
• Max Cable Length: 6 m (input and output)
• USB Signal Type: USB 1.1 for keyboard and mouse (USB emulation)
• Operation: Front-panel buttons

Connections:

• To Computers: (2), (4), or (8) 20-pin
