BlackBox SS8P-KM-UCAC SECURE KM SWITCH, 8-PORT, USB, CAC

Secure KM-Switch, NIAP 3.0

The Secure KM-Switch enables instant switching between up to 8 computers and connected displays using Glide-and-Switch technology while ensuring top-notch data security. Ideal for organizations managing sensitive data across isolated networks.

- Glide-and-Switch Technology: Seamlessly switch between up to eight systems by moving the cursor to the target display.
- Optimized for secure environments, protecting data from unauthorized access and accidental transfer.
- NIAP Certification: Tested to NIAP Protection Profile Version 3.0 standards.
- Optically isolated USB ports ensure electrical isolation of USB data paths.
- Protected firmware prevents unauthorized reprogramming or data access.
- Automatic cache clearing of keyboard and internal data to prevent leaks.
- Tamper-proof housing with physical intrusion protection.
- OS Compatibility: Supports Windows, Mac, and Linux.
- Balanced-speaker output and audio switching support.
- Locking power supply.
- Optional: Fully advanced and configurable CAC port for specific peripheral allocation.
- TEMPEST options available (contact sales for details).
- Warranty: 3-Year Double Diamond™.

Secure KM-Switches for Isolated System Control
These KM-Switches are ideal for operating 4 or 8 isolated computers through a single user console. Each computer retains a direct monitor connection, allowing real-time monitoring of all systems. The operator can switch between systems simply by moving the cursor, enabling a seamless transition without buttons or hotkeys – ideal for public safety, defense, and finance applications.

Comprehensive Secure KVM Switch Portfolio by Black Box:

- Available with 2, 4, 8, or 16 computer ports.
- 4K digital and analog options for consoles with up to four monitors.
- Matrix switches for up to four users.
- Isolation protection through the 1-Port KVM Protector for single systems.

Technical Specifications:

- Certifications: NIAP PP3.0, CE, RoHS compliant.
- USB Signal: USB 1.1 emulation for keyboard and mouse.
- Ports:
- Computer: 4 or 8 USB Type B (CAC option available).
- Console: 2 USB Type A for keyboard and mouse, 1 USB Type A (CAC option).
- Audio Inputs: 4 or 8 x 3.5 mm stereo jacks.
- Audio Output: 1 x 3.5 mm stereo jack.
- Power Supply: External locking power adapter, 100 - 240 VAC, 12 VDC, 3 A.
- Temperature Range: Operating 0 - 40 °C, Storage -20 - 60 °C.
- Humidity: 0 - 80%, non-condensing.
- Weight:
- 4-Port Models: 1.9 kg.
- 8-Port Models: 2.85 kg.
- Dimensions:
- 4-Port Models: 319 W x 45 H x 170 D mm.
- 8-Port Models: 432 W x 45 H x 221 D mm.

TAA-Compliant: Yes
