BlackBox SS8P-DVI-8X4-UCAC SECURE KVM MTRX SWITCH, SH, 8-PORT, DVI-I, USB, CAC, 8x4

Secure KVM-Matrix-Switches, NIAP 3.0, DVI-I Single-Head

Enable up to two or four users to securely control up to eight computers, providing full information security. Perfectly suited for organizations managing sensitive data across networks with varying security levels.

- Reliable access to multiple computers across different networks.
- Protects against unintended data transfers, unauthorized access, and data corruption.
- Designed for organizations with isolated networks handling confidential data.
- Certified to NIAP Protection Profile Version 3.0.
- Compatible with Windows, Mac, and Linux OS.
- DVI-I video with dual-link support up to 2560 x 1600, USB, and audio.
- Secure EDID learning and emulation for seamless monitor compatibility.
- Supports balanced speaker outputs and audio switching.
- Locking power supply for additional security.
- Configurable CAC port for assigned peripherals.
- Warranty: 3-Year Double Diamond™.

Key Security Features:

- Isolated data channels prevent any data flow between secure ports and the outside world.
- Mechanical, electrical, and optical isolation protects against hacking and data leaks.
- Protected firmware prevents unauthorized reprogramming or reading.
- Cache and keyboard inputs are automatically cleared after each switch.
- Tamper-proof enclosure with tamper-resistant locking mechanisms.

Black Box NIAP PP3.0-certified KVM switches offer secure desktop access protection for government agencies, financial institutions, healthcare, and educational sectors. The KVM switch series enables secure switching between up to 16 PCs, servers, or thin clients at an ergonomic workstation.

Extensive Selection for All Applications:

- KVM switches with 2, 4, 8, or 16 computer ports.
- Digital and analog 4K options for consoles with up to four monitors.
- Matrix switches for up to four users.
- Multiviewer with 4-in-1 display.
- 1-Port KVM Protector.

Models and Connections:

- Models:
- 4x2 Matrix: Supports two users and four computers.
- 8x2 Matrix: Supports two users and eight computers.
- 4x4 Matrix: Supports four users and four computers.
- 8x4 Matrix: Supports four users and eight computers.
- Connections per Model:
- Computer Side: DVI-I (Single/Dual-Link), USB-B for keyboard/mouse, audio.
- User Side: DVI-I, USB-A for keyboard/mouse, audio, CAC.

Technical Specifications:

- Certifications: NIAP PP3.0, CE, RoHS, UL, TAA-compliant.
- Video Format: DVI-I (Single-Link, Dual-Link, VGA, HDMI via adapter).
- Max Resolution: 2560 x 1600 (Dual-Link DVI), 4K UHD with HDMI/DVI adapter.
- Max Pixel Clock: 248 MHz.
- Cable Length: Up to 6 m input/output.
- USB Type: USB 1.1 emulation for keyboard and mouse.
- Power Supply: External, lockable, 100 - 240 VAC, 12 VDC, 3 A.

Operating Conditions:

- Temperature: 0 to +40 °C (Operating), -20 to +60 °C (Storage).
- Humidity: Up to 80%, non-condensing.

Dimensions:

- 4x2 and 4x4 Matrix: 319 W x 69 H x 170 D mm.
- 8x2 and 8x4 Matrix: 432 W x 69 H x 221 D mm.

Weight:

- 4-Port Models: 1.9 kg.
- 8-Port Models: 2.85 kg.

TAA-compliant: Yes.
