BlackBox SS8P-DVI-8X2-UCAC SECURE KVM MTRX SWITCH, SH, 8-PORT, DVI-I, USB, CAC, 8x2

Secure KVM-Matrix-Switches, NIAP 3.0, DVI-I Single-Head

Enable up to four users to control up to eight computers with full information security. Ideal for organizations managing sensitive data across networks with varying security levels.

- Secure access to multiple computers connected across different networks.
- Protects against unwanted data transfers, unauthorized access, and data corruption.
- Designed for organizations with sensitive data in isolated networks.
- Certified to NIAP Protection Profile Version 3.0.
- Compatible with Windows, Mac, and Linux OS.
- DVI-I, USB, and Audio; supports Dual-Link DVI up to 2560 x 1600.
- Secure EDID emulation enables compatibility with most monitors.
- Supports balanced speaker outputs and audio switching.
- Locking power supply for additional security.
- Configurable CAC port for assigned peripherals.
- Warranty: 3-Year Double Diamond™.

Security Features:

- Isolated data channels prevent data flow between ports and the outside world.
- Mechanical, electrical, and optical isolation protects against hacking and data leaks.
- Protected firmware prevents unauthorized programming and reading.
- Automatic cache and keyboard input clearing upon each switch.
- Tamper-proof enclosure with tamper-resistant switches and seals.

The Black Box NIAP PP3.0-certified KVM switch line offers secure desktop access protection for government agencies, defense, finance, healthcare, and educational sectors. It allows secure switching between up to 16 PCs, servers, or thin clients.

Extensive Portfolio for All Applications:

- KVM switches with 2, 4, 8, or 16 computer ports.
- 4K options for digital and analog video with up to four monitors.
- Matrix switches supporting up to four users.
- Multiviewer with 4-in-1 display.
- 1-Port KVM Protector.

Connections and Models:

- Models:
- 4x2 Matrix: Supports two users and four computers.
- 8x2 Matrix: Supports two users and eight computers.
- 4x4 Matrix: Supports four users and four computers.
- 8x4 Matrix: Supports four users and eight computers.
- Per Model Connections:
- Computer Side: DVI-I (Single/Dual-Link), USB-B for keyboard/mouse, audio.
- User Side: DVI-I, USB-A for keyboard/mouse, audio, CAC.

Technical Specifications:

- Certifications: NIAP PP3.0, CE, RoHS, UL, TAA-compliant.
- Video Format: DVI-I, HDMI via adapter.
- Max Resolution: 2560 x 1600 (Dual-Link DVI), 4K UHD with HDMI/DVI adapter.
- Max Pixel Clock: 248 MHz.
- Cable Length: Up to 6 m input/output.
- USB Type: USB 1.1 emulation for keyboard and mouse.
- Power Supply: External, lockable, 100 - 240 VAC, 12 VDC, 3 A.

Operating Conditions:

- Temperature: 0 to +40 °C (Operating), -20 to +60 °C (Storage).
- Humidity: Up to 80%, non-condensing.

Dimensions:

- 4x2 and 4x4 Matrix: 319 W x 69 H x 170 D mm.
- 8x2 and 8x4 Matrix: 432 W x 69 H x 221 D mm.

Weight:

- 4-Port Models: 1.9 kg.
- 8-Port Models: 2.85 kg.

TAA-compliant: Yes.
