BlackBox SS4P-DH-HDMI-UCAC SECURE KVM SWITCH, DH, 4-PORT, HDMI, USB, CAC

Secure KVM Switch, NIAP 3.0, 4K HDMI Dual-Head

Control up to four computers with a single user console while ensuring top-level data security. This NIAP-certified KVM switch is ideal for organizations that handle sensitive data across separate networks with varying security levels.

Provides secure access to multiple computers across different networks.
Prevents unintended data transfers, unauthorized access, and potential data loss.
Ideal for government agencies, finance, healthcare, and all high-security environments.
Certified to NIAP Protection Profile Version 3.0.
Supports Windows, Mac, and Linux.
Dual 4K HDMI channels up to 3840 x 2160 at 60 Hz.
Secure EDID learning and emulation ensure monitor compatibility.
Supports balanced audio and audio switching.
Lockable power supply for secure operation.
Advanced CAC port options allow assignment of specific peripherals.
Warranty: 3 years Double Diamond™ (Standard).

Security Features:

Each port has isolated data channels to prevent cross-transfer between secure ports and external devices.
Mechanical, electrical, and optical isolation protects against hacking and data leaks.
Protected firmware prevents reprogramming and unauthorized reading.
Automatically clears keyboard and internal cache.
Tamper-resistant casing with built-in intrusion protection.

Technical Details:

Video Format: HDMI
Maximum Resolution: 4K UHD 3840 x 2160 at 60 Hz
Pixel Clock: 248 MHz
DDC: 5 Volts p-p (TTL)
Data Rate: 1.65 Gbps
Input EQ: automatic

USB Type: USB 1.1 for keyboard and mouse only (emulated)

Connections to Computers:

• (4) or (8) HDMI
• (2) or (4) USB Type B for keyboard and mouse
• Additional CAC options: (2) or (4) USB Type A
• (2) or (4) 3.5-mm audio jacks

Connections to User Console:

• (2) HDMI
• (2) USB Type A for keyboard and mouse
• CAC options: (2) USB Type A
• (1) 3.5-mm audio jack

Operating Temperature: 0 to +40 °C
Storage Temperature: -20 to +60 °C
Relative Humidity: 0 to 80%, non-condensing

Dimensions and Weight:

• 2-port models: 224 W x 67 H x 170 D mm, Weight: 1.75 kg
• 4-port models: 318 W x 44.7 H x 170 D mm, Weight: 1.9 kg

Certifications:

• NIAP PP3.0 certified
• CE
• RoHS-compliant
• UL
• TAA-compliant
