BlackBox SS4P-DH-DP-UCAC SECURE KVM SWITCH, DH, 4-PORT,DP,USB,CAC

Secure KVM Switch, NIAP 3.0, 4K DisplayPort Dual-Head

Control up to four computers with a single user console while ensuring complete information security. This NIAP-certified KVM switch provides secure connectivity across different networked computers, ideal for organizations managing sensitive data across networks with varying security levels.

Enables secure access to multiple network-connected computers.
Protects critical data from accidental transfers, unauthorized access, and damage.
Certified to NIAP Protection Profile Version 3.0.
Supports Windows, Mac, and Linux OS.
Dual 4K DisplayPort channels at 3840 x 2160 at 30 Hz.
Secure EDID learning and emulation for compatibility with most monitors.
Supports balanced speaker outputs and audio switching.
Lockable power supply.
Configurable CAC port allows assignment of specific peripherals.
TEMPEST options available upon request.
Warranty: 3 years Double Diamond™ (Standard).

Security Features:

Each port features isolated data channels to prevent data leaks.
Mechanical, electrical, and optical isolation to prevent hacking.
Protected firmware to prevent reprogramming or unauthorized reading.
Keyboard/internal cache clearing between switches.
Case intrusion protection and tamper-proof seals.

Technical Details:

Video Formats: DisplayPort 1.2
Maximum Resolution: 4K UHD 3840 x 2160 at 30 Hz
Pixel Clock: 248 MHz
DDC: 5 Volts p-p (TTL)
Data Rate: 1.65 Gbps
Automatic input equalization

USB Type: USB 1.1 for keyboard and mouse only (emulated)

Connections to Computers:

• (4) or (8) 20-pin DisplayPort sockets
• (2) or (4) USB Type B for keyboard and mouse
• Additional CAC options: (2) or (4) USB Type A
• (2) or (4) 3.5-mm audio jacks

Connections to User Console:

• (2) 20-pin DisplayPort sockets
• (2) USB Type A for keyboard and mouse
• CAC options: (2) USB Type A
• (1) 3.5-mm audio jack

Operating Temperature: 0 to +40 °C
Storage Temperature: -20 to +60 °C
Relative Humidity: 0 to 80% non-condensing

Dimensions and Weight:

• 2-port models: 224 W x 67 H x 170 D mm, Weight: 1.74 kg
• 4-port models: 319 W x 45 H x 170 D mm, Weight: 1.9 kg

Certifications:

• NIAP PP3.0 certified
• CE
• RoHS
• UL
• TAA-compliant
