BlackBox LSP442 SFP+ 10GE SM 1310NM

SFP+, 10-Gbps

The 10-Gbps SFP+ transceiver provides a flexible and reliable solution for fiber data communication, ideal for enterprise and telecommunications applications. With its compact design and durable metal housing, it offers effective EMI shielding and ESD protection. The transceiver is hot-swappable and interchangeable, making it suitable for dynamic networks and easy maintenance.

Equipped with an LVPECL-compatible interface, the SFP+ transceiver supports the standard wavelength spectrum as defined by ITU G.694.2. Compliance with MSA SFF-8472 and INF-8077i ensures high interoperability with other network devices. Digital diagnostic capabilities and loopback functions facilitate maintenance on managed platforms, enabling quick fault identification.

Key Features:

• SFP+ package with duplex LC connector for flexible fiber connections
• Power consumption under 1 W for energy-efficient operation
• LVPECL-compatible data input/output interface
• IEC-60825 compliant for laser safety
• Sturdy metal housing for EMI and ESD protection
• MSA SFF-8472 and INF-8077i compliant
• Hot-swappable for easy in-service replacement

Technical Specifications:

Approvals:

• CE, FCC

Connectors:

• Duplex LC

Transmission Distance:

• LSP441: 300 m (multimode, 850 nm)
• LSP442: 20 km (single-mode, 1310 nm)

Transmission Speed:

• 10.3 Gbps

Fiber Type:

• LSP441: 50-micron multimode, 850 nm
• LSP442: 9-micron single-mode, 1310 nm

Power Supply:

• Input: 3.3 V
• Power consumption: <1 W
• Powered through SFP cage

Environmental Conditions:

• Operating temperature: 0 to 70 °C
• Storage temperature: -40 to 85 °C
• Operating humidity: 5 to 85 %, non-condensing

Dimensions:

• 8.5 H x 13.7 W x 55.4 D mm

Weight:

• 0.016 kg

Additional Features:

• Supports digital diagnostics and loopback functions on managed platforms
• ITU G.694.2 standard wavelength spectrum supported
