BlackBox LPJ008A-T-R2 AT 8-Port 10/100/1000 PoE Injector content_copy

PoE Gigabit Ethernet Injector – 802.3at

This 802.3at-compliant PoE Gigabit Ethernet injector supplies up to 30 watts per port, providing a safe, efficient solution for powering PoE devices over a single Ethernet cable. The injector supports high-speed devices with Gigabit data connections and comprehensive protection against overload, surge, overcurrent, and short-circuits. Ideal for delivering power to PoE devices at remote locations, it eliminates the need for additional power outlets.

Fully backward-compatible with 802.3af devices, this injector is perfect for powering access points, IP cameras, VoIP phones, and LCD displays. With plug-and-play installation and diagnostic LEDs for device detection and error alerts, the injector integrates seamlessly into any network. Midspan data connections with 10/100/1000 Mbps support and over-temperature protection enhance this device’s reliability.

Key Features:

• 802.3at-compliant midspan injector, delivers up to 30 watts per device
• Supports Gigabit data connections for high-speed devices (10/100/1000 Mbps)
• Reliable overload, surge, overcurrent, and short-circuit protection
• Over-temperature protection with automatic shutdown
• Cost-effective cabling solution for simultaneous power and data transmission
• Ideal for access points, PTZ cameras, IP phones, and LCD displays
• Backward compatible with 802.3af standard devices
• Quick plug-and-play installation for easy setup

Technical Specifications:

Applications:

• Corporate networks with PoE requirements, including IP cameras, wireless access points, and VoIP phones

Standards and Certifications:

• CE, RoHS 2, cUL/UL

Data Rate:

• Supports 10/100/1000 Mbps

Power Capacity (model-dependent):

• LPJ001A-T-R2: Maximum 30 W
• LPJ008A-T-R2: Maximum 250 W
• LPJ016A-T-R2: Maximum 500 W

Connections:

• Data input: 1, 8, or 16 RJ-45 (10/100/1000 Mbps)
• Data/PoE output: 1, 8, or 16 RJ-45 (10/100/1000 Mbps)

Power Supply:

• Input voltage range: 90–264 VAC, rated voltage: 100–240 VAC, 47–63 Hz
• Output voltage: 54–57 VDC under all conditions

Dimensions:

• LPJ001A-T-R2: 2.8 x 4.6 x 14 cm
• LPJ008A-T-R2 and LPJ016A-T-R2: 4.6 x 43.9 x 21.8 cm

Weight:

• LPJ001A-T-R2: 0.2 kg
• LPJ008A-T-R2: 2.7 kg
• LPJ016A-T-R2: 3.2 kg

Environmental Conditions:

• Humidity: 5–90% (non-condensing)
• Operating temperature: -10 to +40 °C
• Storage temperature: -20 to +70 °C

Additional Features:

• Diagnostic LEDs for device detection and error alerts
