BlackBox LPJ000A-F-R3 AF 1-PORT 10/100/1000 POE INJECTOR

PoE Gigabit Ethernet Injector – 802.3at

This 802.3at-compliant PoE Gigabit Ethernet injector provides up to 30 watts per port, offering a fast and secure way to power PoE+ devices like IP cameras, access points, and VoIP phones. Supporting Gigabit data connections, this injector allows simultaneous transmission of data and power over a single Ethernet cable, minimizing installation effort and making it especially cost-effective.

Equipped with overload, surge, overcurrent, and short-circuit protection, this PoE injector ensures top safety. It is backward-compatible with 802.3af devices, making it ideal for locations where installing additional power lines is impractical, such as remote sites or movable network nodes. Thanks to its plug-and-play installation, the injector is ready to use in any enterprise network.

Key Features:

• 802.3at-compliant midspan injector, providing up to 30 watts per device
• Supports Gigabit Ethernet data connections at 10/100/1000 Mbps
• Includes overload, surge, overcurrent, and short-circuit protection
• Over-temperature protection with automatic shutdown to prevent damage
• Easy setup, no additional power supplies needed
• Ideal for access points, PTZ cameras, IP phones, and other PoE/PoE+ devices
• Backward compatible with 802.3af standards

Technical Specifications:

Applications:

• PoE power supply for access points, security cameras, VoIP phones, LCD displays

Standards:

• Compliance: CE, RoHS 2, cUL/UL

Data Rate:

• 10/100/1000 Mbps

PoE Power:

• Maximum output per port: 30 W

Power Capacity (model-dependent):

• LPJ001A-T-R2: 30 W
• LPJ008A-T-R2: 250 W
• LPJ016A-T-R2: 500 W

Connections:

• Data input: 1, 8, or 16 RJ-45 (10/100/1000 Mbps)
• Data/PoE output: 1, 8, or 16 RJ-45 (10/100/1000 Mbps)

Power Supply:

• Input voltage range: 90–264 VAC, rated voltage: 100–240 VAC, 47–63 Hz
• PoE output voltage: 54–57 VDC (under all conditions)

Dimensions:

• LPJ001A-T-R2: 2.8 x 4.6 x 14 cm
• LPJ008A-T-R2 and LPJ016A-T-R2: 4.6 x 43.9 x 21.8 cm

Weight:

• LPJ001A-T-R2: 0.2 kg
• LPJ008A-T-R2: 2.7 kg
• LPJ016A-T-R2: 3.2 kg

Environmental Conditions:

• Humidity: 5–90% (non-condensing)
• Operating temperature: -10 to +40 °C
• Storage temperature: -20 to +70 °C

Additional Features:

• Diagnostic LEDs for device detection and error alerts
• Simple plug-and-play installation
