BlackBox LGC281A GIGABIT INDUSTRIAL MEDIA CONVERTER MM SC

Industrial Gigabit Media Converters - LGC280 Series

Convert 10/100/1000Base-T(X) to 1000Base-X in Harsh Environments

Conversion: 10/100/1000Base-T(X) to 1000Base-X
Jumbo Frames up to 10,240 bytes
Store-and-forward transmission for optimized network performance
Relay output with a capacity of 1 A at 24 VDC
Robust IP30 enclosure for maximum protection in industrial settings
Flexible mounting options: DIN rail or wall mount

Extend Your Network with Fiber
These media converters provide an economical way to integrate fiber into your existing network infrastructure. They easily convert copper to fiber, offering extended network solutions for remote sites and extending network reach.

Built for Harsh Environments
The industrial-grade LGC280 series media converters ensure consistent network performance even in the harshest conditions. Operating temperatures range from -40 °C to 70 °C, and the rigid IP30-rated housing, along with certifications, guarantee stable performance in demanding environments.

Specifications:

Approvals: CE, FCC

Standards:

• IEC60068-2 (Shock, Free Fall, Vibration)
• IEEE 802.3 (10Base-T)
• IEEE 802.3u (100Base-TX)
• IEEE 802.3ab (1000Base-T)
• IEEE 802.3z (1000Base-X)

Filtering and Forwarding Rates:

• 10 Mbps: 14,880 pps
• 100 Mbps: 148,800 pps
• 1 Gbps: 1.48 Mpps

Jumbo Frames: Up to 10,240 bytes

Status Indicators:

• Power: Green (2 power LEDs)
• Fault: Yellow (indicates power failure)
• RJ45 Port (10/100/1000Base-T(X)): Green for Link/Act, Yellow for 100 Mbps indication
• 1000Base-X Port: Green for Link/Act

DIP Switch: Enable/disable relay output function

Fiber Type:

• LGC280A: Depending on SFP module
• LGC281A: Multimode
• LGC282A: Singlemode

Wavelength:

• LGC280A: Depending on SFP module
• LGC281A: 850 nm
• LGC282A: 1310 nm

Link Budget:

• LGC280A: Depends on SFP module
• LGC281A: 8.5 dB
• LGC282A: 10.5 dB

Maximum Distance:

• LGC280A: Depends on SFP module
• LGC281A: 550 m
• LGC282A: 10 km

Ports:

• LGC280A: (1) RJ45 10/100/1000BASE-T, (1) SFP slot 1000 Mbps
• LGC281A: (1) RJ45 10/100/1000BASE-T, (1) SC pair (Multimode)
• LGC282A: (1) RJ45 10/100/1000BASE-T, (1) SC pair (Singlemode)

Power Supply:

• Input: Two 12–48 V DC inputs on a 6-pin terminal block
• Typical power consumption: 3.5 watts
• Overload and reverse polarity protection: Included

Environmental Conditions:

• Humidity: 5–95% non-condensing
• Operating Temperature: -40 to 70 °C
• Storage Temperature: -40 to 85 °C

Dimensions:

• 26.1 x 94.9 x 144.3 mm (H x W x D)

Weight:

• LGC280A: 0.379 kg
• LGC281A/LGC282A: 0.399 kg

TAA Compliant: YES
