BlackBox LGC280A GIGABIT INDUSTRIAL MEDIA CONVERTER SFP

Industrial Gigabit Media Converters LGC280 Series

These rugged media converters transform 10/100/1000Base-T(X) to 1000Base-X, designed for extreme environments, allowing for seamless fiber extension to your existing network infrastructure.

Converts 10/100/1000Base-T(X) to 1000Base-X.
Supports jumbo frames up to 10,240 bytes.
Store-and-forward transmission for efficient data handling.
Relay output with a capacity of 1 A at 24 VDC.
Sturdy IP30-rated casing for enhanced durability.
Easy installation with options for DIN-rail or wall mounting.

Extend Your Network with Fiber
This media converter is a cost-effective way to add fiber to your network, ideal for extending connections to harsh environments requiring high temperature tolerance and vibration resistance.

Built for Harsh Environments
Operating in temperatures from -40 to 70 °C, the converter features an IP30-rated casing and industrial certifications, ensuring reliable performance in challenging settings.

Technical Specifications:

Certifications: CE, FCC, IEC60068-2 (shock, free fall, vibration)

Standards:

• IEEE 802.3 (10Base-T)
• IEEE 802.3u (100Base-TX)
• IEEE 802.3ab (1000Base-T)
• IEEE 802.3z (1000Base-X)

Filtering and Forwarding Rates:

• 10 Mbps: 14,880 pps
• 100 Mbps: 148,800 pps
• 1 Gbps: 1.48 Mpps

Jumbo Frame Support: Up to 10,240 bytes

Indicators:

• Power Indicator: Green (Power LED x2)
• Fault Indicator: Yellow (Power Failure)
• RJ45 Port Indicator: Green (Link/Act), Yellow (100 Mbps)
• 1000Base-X Port Indicator: Green (Link/Act)

DIP Switch: Enables/disables relay output

Fiber Type:

• LGC280A: Dependent on SFP module
• LGC281A: Multimode
• LGC282A: Singlemode

Wavelength:

• LGC280A: Based on SFP module
• LGC281A: 850 nm
• LGC282A: 1310 nm

Link Budget:

• LGC280A: Based on SFP module
• LGC281A: 8.5 dB
• LGC282A: 10.5 dB

Maximum Distance:

• LGC280A: Dependent on SFP module
• LGC281A: 550 m
• LGC282A: 10 km

Ports:

• LGC280A: (1) RJ45 10/100/1000BASE-T, (1) SFP slot 1000 Mbps
• LGC281A: (1) RJ45 10/100/1000BASE-T, (1) SC pair (Multimode)
• LGC282A: (1) RJ45 10/100/1000BASE-T, (1) SC pair (Singlemode)

Power:

• Input: Dual 12–48 V DC inputs via 6-pin terminal block
• Typical Power Consumption: 3.5 Watts
• Overload and reverse polarity protection: Included

Environmental:

• Humidity: 5–95% non-condensing
• Operating Temperature: -40 to 70 °C
• Storage Temperature: -40 to 85 °C

Dimensions:

• 26.1 x 94.9 x 144.3 mm (H x W x D)

Weight:

• LGC280A: 0.379 kg
• LGC281A/LGC282A: 0.399 kg

TAA Compliant: YES
