BlackBox LFP443 SFP 10/100/1000BASE-T RJ45 SGMII

SFP, 1250-Mbps, SGMII

Modular, flexible optical transceivers for data communication equipment.

- Supports 10/100/1000 BASE-T operation in host systems with SGMII interface.
- Bidirectional data connections up to 1.25 Gbps for Gigabit Ethernet over CATx cables.
- Hot-swappable, suitable for SFP slots.
- Low power consumption (1.05 W typical).
- Durable RJ-45 connector assembly.
- Full-metal casing to reduce EMI.
- Extended operating temperature range from 0 °C to +70 °C.
- Warranty: 1-Year Double Diamond™ (Standard)

This 10/100/1000 BASE-T copper SFP transceiver complies with the SFP Multi-Source Agreement (MSA) and is compatible with IEEE 802.3 Gigabit Ethernet standards. The transceiver provides access to the 10/100/1000 BASE-T Physical Layer Chip (PHY) via I2C, allowing full access to PHY settings and functions. Supports 1000BASE-X Auto-Negotiation but lacks a link indication feature (RX_LOS is internally grounded).

Specifications:

Approvals:
- CE, FCC, RoHS compliant and lead-free

Connectors:

- RJ-45

Cable Type:

- CATx

Transmission Range:

- Up to 100 m

Data Rate:

- 1.25 Gbps

Power Supply:

- Powered via SFP cage
- Input Voltage: 3.3 V
- Power Consumption: 1.1 W

Environmental Conditions:

- Operating Temperature: 0 to 70 °C
- Storage Temperature: -40 to 85 °C
- Operating Humidity: 5 to 85%, non-condensing

Dimensions and Weight:

- Dimensions: 1.4 x 1.4 x 6.8 cm (W x H x D)
- Weight: 0.016 kg
