Bernstein 6021190100 GC-SU1 FF limit switch metal position switch Ö/S IP65 spring guide 602119010 content_copy

The limit switch GC-SU1 FF from Bernstein is a metal-encapsulated end switch, designed for various applications in the field of safety applications and position detection due to its compact design. It serves as a mechanical switch for detecting end positions or as a safety component in industrial systems. The robust metal housing construction ensures high mechanical stability and protection against external influences. The switch is designed for use in demanding environments where reliability and long service life are required.

Applications

The GC-SU1 FF is used in industrial automation, particularly in systems requiring precise position detection or mechanical movement limitation. Typical application scenarios include machine building, material handling technology, machine tools, and systems with moving parts where a secure end point or position signal is required. The compact design allows for flexible installation even in confined spaces.

Functions and Equipment in Detail

The switch features screw terminals with self-lifting clamping washers, enabling secure and easy connection of cables. The clamping washers prevent the connection cables from being accidentally disconnected. Additionally, non-loosening cover screws are integrated, facilitating the removal and reinstallation of the housing cover without losing screws. The switching system is easily replaceable via a latching holder, simplifying maintenance and repair and minimizing downtime.

Technology Explained Simply

The limit switch operates mechanically and is actuated by a spring rod, which triggers the switch upon contact with a moving part. The metal housing construction provides high protection against mechanical stress and environmental influences. The protection rating IP65 (dust-tight and protected against water jets) makes the switch suitable for outdoor use or in humid environments. The spring guidance ensures precise and reliable actuation of the switch, guaranteeing high switching accuracy.

Compatibility and Accessories

The GC-SU1 FF is available in various versions, including variants with customer-specific cables and connection plugs, enabling individual adaptation to existing systems. These options allow flexible integration into existing control systems without additional modifications. The exact selection of accessory components depends on the specific requirements of the respective system.

Mounting and Installation

The switch is mounted using integrated mounting elements, ensuring secure and stable anchoring. The self-lifting clamping washers and non-loosening cover screws simplify installation and maintenance. The latching holder of the switching system allows for quick replacement without tools, reducing installation time. The compact design allows flexible placement at various locations on the machine or system.

Advantages in Operation

The GC-SU1 FF offers high operational reliability due to its robust construction and simple mounting and maintenance features. The spring guidance ensures reliable switching function, while the protection rating IP65 enables use in humid or dusty environments. Integrated mounting aids such as self-lifting clamping washers and non-loosening cover screws reduce maintenance effort and increase efficiency during installation and servicing. The ability to easily replace the switching system reduces downtime in case of defects.

General
Degree of protection	IP65
Switching system	Spring-rod
Clamping washers	self-releasing
Cover screws	non-removable
Switching system replacement	via snap-in holder
Accessories	Customer-specific cables and connectors

---
