Benning VT 2 non-contact phase magnetic field tester 044055 content_copy

Benning VT 2. Non-contact phase and magnetic field tester. Test type 1-pole. Single-pole phase display yes, red LED/buzzer. Phase testing on sockets, junction boxes, switches, cables and lamps, etc. Very reliable phase testing on various protective contact and CEE sockets (including 63 A when high sensitivity is activated). Non-contact voltage detection yes. Testing of insulated cables, such as cable drums, fairy lights, for cable breaks. Display via red test tip and buzzer. Flashing frequency of the LED test tip and buzzer frequency increases with the voltage depth. Capacitive measuring method does not require any current flow. Low self-discharge for increased battery life/readiness for use. Voltage display LED. Voltage measuring range 12 V/ 200 V - 1000 V AC. 12 V voltage range can be switched on using a button. To determine whether there is no voltage, please only use a 2-pole voltage tester in accordance with DIN EN 61243-3 (VDE 0682-401), e.g. a DUSPOL voltage tester. Can be used in precipitation, yes, protection class IP 53. Testing of magnetic fields (permanent, AC and DC induced). Testing of solenoid valves in pneumatic and hydraulic systems, heating systems and pumps. Testing of relays/contactors in vehicles, machines, devices and controls. Magnetic field display via green LED test tip. Integrated test magnet for function testing. Break-proof ABS housing and easy operation. Measuring circuit category Cat IV. Max. voltage measuring circuit category 600 V. Measuring circuit category Cat III. Max. voltage measuring circuit category 1000 V. Length 153 mm. Blade length 12 mm. Blade width 3 mm. Weight 40 g including batteries. Power supply battery. Includes 2 x 1.5 V Micro/ AAA/ LR03 battery, pen clip.
Type: BENNING VT 2
