Beha 4014969 9040EUR rotating field indicator with LCD display

Your rating:
Average rating
product review for Beha 4014969 9040EUR rotating field indicator with LCD display
( 4.4 / 5 ) 9 ratings
Beha 4014969
This image may differ from the desired article.
Beha 4014969Beha 4014969
-6% 323,00 EUR 344,08 EUR
( 384,37 EUR incl. VAT )
≈ £270.35  |  ≈ $354.98
plus delivery charges: 55,00 €
Made to order · Delivery time approx. 20 workdaysinfo_outline
1x Beha 4014969 9040EUR rotating field indicator with LCD display
Lieske Part No.:453917
Mfg Part No: 4014969
UPC/EAN: 0095969599474
Weight:0.677 kg
Type:9040EUR

Product information for Beha 4014969:

The Beha rotating field indicator type 9040EUR is a measuring instrument for determining the phase sequence in three-phase power systems. It assists electrical specialists and technicians during testing and commissioning of electrical installations, particularly for verifying the rotation direction of three-phase motors or the correct phase sequence in distribution networks. The device features an LCD display that visually represents the three phases and simultaneously indicates the rotating field direction. The display is designed for good contrast to ensure clear readability even under very bright lighting conditions.

Applications
The rotating field indicator 9040EUR is primarily used in the field of electrical installation and industrial electrical engineering. It enables quick and reliable determination of phase sequence in three-phase systems, which is important during commissioning of motors, transformers, or during maintenance of distributors. The indication of rotation direction helps identify incorrect connections or wrong phase sequences that could cause damage to electrical machines. The device is designed for use in electrical installations with three-phase power supply.

Functions and equipment in detail
The device displays the three phases of a three-phase system, with the display shown on an LCD screen. The representation of the phases is designed to make the rotating field direction recognizable, allowing the user to immediately determine whether the rotating field rotates clockwise or counterclockwise. The rapid determination of phase sequence is a central feature that increases work efficiency during installation testing. The LCD display is designed to remain clearly readable even under bright ambient lighting, facilitating operation outdoors or in well-lit rooms.

Technology explained simply
The rotating field indicator 9040EUR operates based on the electrical voltage of the three phases. It detects phase shifts and the temporal sequence of voltage peaks to determine the rotation direction of the rotating field. The LCD display visualizes the three phases and their sequence, allowing the user to directly recognize the phase sequence. The contrast optimization of the display ensures that the representation remains clearly visible even under direct sunlight or in strongly lit environments. The device is designed for use in three-phase networks without requiring special power supply or external energy sources.

Compatibility and accessories
The device is designed for use in three-phase networks featuring standard phase connections (L1, L2, L3). No additional adapters or accessories are required for basic functionality. The application is performed directly on the phase conductors, with measurement carried out without additional power supply or external energy source.

Mounting and installation
Installation is performed by directly connecting the sensors to the three phase conductors of the three-phase network. No special mounting or permanent installation is required; the device is temporarily connected to the conductors to check the phase sequence. Operation involves simply attaching the sensors, after which the display immediately shows the phase sequence and rotation direction.

Advantages in operation
The rotating field indicator 9040EUR enables quick and visual verification of phase sequence, reducing working time during commissioning or maintenance of electrical installations. The LCD display with high contrast ensures clear representation even under unfavorable lighting conditions. The direct indication of rotating field direction helps quickly identify error sources without requiring additional measuring instruments or calculations. The device is easy to operate and requires no special preparation or adjustment.

Batteries are not included in the delivery scope.

General
Display technologyLCD
Functionindication of the three phases
Propertyrapid determination of phase sequence
Display propertyGood contrast
Application areathree-phase power supply network
