Beha 3313412 FTC00001240D three-phase adapter 16 A
|
137,75 EUR 139,59 EUR |
|
|
( 163,92 EUR incl. VAT ) ≈ £114.75 | ≈ $151.11 plus delivery charges: 55,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| Lieske Part No.: | 482101 |
|---|---|
| Mfg Part No: | 3313412 |
| UPC/EAN: | 0095969464444 |
| Weight: | 0.34 kg |
| Type: | FTC00001240D |
Product information for Beha 3313412:
Applications
The adapter is primarily used in the field of electrical safety testing, especially for mobile devices operated via a three-phase connection with a 16 A CEE 5-pole plug. This includes, for example, tools, machines, or equipment in industry, construction, or manufacturing that must be regularly tested for electrical safety. The adapter is used in conjunction with test devices equipped with a safety plug connector type 1240 to ensure safe and standard-compliant measurement of electrical safety parameters.
Functions and Equipment in Detail
The three-phase adapter features a 16 A CEE 5-pole plug that connects to the device under test. On the other side, it has a safety plug connector type 1240, which connects to the test device. This establishes a secure and electrically correct connection between the device and the test device. The adapter’s function is to correctly transmit electrical parameters—particularly earth conductor resistance and insulation resistance—during testing, without requiring additional connections or adapters. The 5-pole configuration ensures complete transmission of all conductors, including the protective earth conductor, which is essential for safety testing.
Technology Explained Simply
The adapter acts as a mechanical and electrical interface between two different plug systems: the 16 A CEE 5-pole plug on the device and the safety plug connector type 1240 on the test device. The 5-pole design includes the three phase conductors (L1, L2, L3), the neutral conductor (N), and the protective earth conductor (PE). This enables a complete electrical connection, which is required for measuring earth conductor resistance and insulation resistance. The use of a specific safety plug connector type 1240 ensures that testing can be carried out in accordance with applicable standards and regulations, as this connector is recognized as a standard for safety testing in electrical specialist practice.
Compatibility and Accessories
The three-phase adapter is specifically designed for test devices equipped with a safety plug connector type 1240. It is therefore compatible with a wide range of test devices used in electrical specialist practice, particularly in industry and construction. It is used in combination with test devices capable of measuring earth conductor resistance and insulation resistance.
Installation and Mounting
Installation is performed by simply plugging the 16 A CEE 5-pole plug into the socket of the device under test. The safety plug connector type 1240 is then connected to the test device. No additional mounting or installation work is required. The connection is mechanically stable and electrically secure, ensuring reliable testing. Handling requires no tools and is straightforward for electrical professionals.
Operational Advantages
Using the three-phase adapter enables quick and secure connection of portable devices to test devices. The 5-pole configuration ensures complete electrical connection, which is crucial for the accuracy of measurement results. The use of a standardized safety plug connector type 1240 ensures compatibility with common test devices and supports compliance with safety regulations. The simple handling reduces testing time and minimizes error sources during connection preparation.
| General | |
| Manufacturer | Beha |
| Amperage | 16 A |
| Connector type | CEE 5-pole |
| Safety connector | Type 1240 |
| Application | inspection of portable equipment with three-phase plug |
