Be quiet! BP030EU Power supply POWER ZONE 2 1200W Modular 80+ Platinum
|
194,92 EUR 196,99 EUR |
|
|
( 231,95 EUR incl. VAT ) ≈ £163.15 | ≈ $218.12 plus delivery charges: 55,00 € |
|
| Delivery time from supplier's stock (ca.) 9 workdaysinfo_outline | |
| In Stock: 2 pieces | |
| Lieske Part No.: | 901787 |
|---|---|
| Mfg Part No: | BP030EU |
| UPC/EAN: | 4260052193563 |
| Weight: | 3.64 kg |
| Type: | CPNT |
Product information for Be quiet! BP030EU:
| Certificates | |
| Compliance certificates | BSMI, CB, CCC, CE, Federal Communications Commission (FCC), RCM, RoHS, TÜV mark, UKCA, WEEE |
| Waste Electrical and Electronic Equipment (WEEE) compliance | |
| Design | |
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 14 cm |
| Number of fans | 1 fan(s) |
| Fan speed | 0 - 2100 RPM |
| Illumination | |
| On/off switch | |
| Logistics data | |
| Shipping (inner) case length | 43 cm |
| Shipping (inner) case width | 26.5 cm |
| Shipping (inner) case height | 34 cm |
| Products per shipping (inner) case | 4 pc(s) |
| Shipping (inner) case gross weight | 14.9 kg |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 0 - 85% |
| Storage relative humidity (H-H) | 0 - 95% |
| Other features | |
| Screws included | |
| Cable ties included | |
| Packaging data | |
| Manual languages | German, English, Spanish, French, Polish, Russian, Ukrainian |
| Package width | 248 mm |
| Package depth | 328 mm |
| Package height | 102 mm |
| Package weight | 3.5 kg |
| Package type | Box |
| Manual | |
| Performance | |
| 80 PLUS certification | 80 PLUS Platinum |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 3.1 |
| EPS version | 2.92 |
| Noise level | 25.5 dB |
| Bearing technology | Rifle |
| Mean time between failures (MTBF) | 100000 h |
| Ports & interfaces | |
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 60 cm |
| Number of SATA power connectors | 7 |
| SATA power cable length | 550,700,850,1000 mm |
| Number of SATA power cables | 2 |
| Peripheral (Molex) power connectors (4-pin) | 1 |
| Peripheral (Molex) power cable length | 1000 mm |
| PCI Express power connectors (6+2 pin) | 3 |
| PCI Express power connectors (12-pin) | 2 |
| PCI Express power cable length | 60 cm |
| CPU P4 connector (4-pin) | 1 |
| CPU power cable length | 70 cm |
| Cabling type | Fully-Modular |
| EPS power connector (8-pin) | |
| CPU power connector (4+4 pin) | |
| PCI Express connector | |
| Power | |
| Total power | 1200 W |
| Peak power | 1270 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Maximum input current (@110V) | 15 A |
| Maximum input current (@220V) | 7.5 A |
| Power factor | 0.97 |
| Number of +12V rail(s) | 1 |
| Combined power (+3.3V) | 120 W |
| Combined power (+12V) | 1200 W |
| Combined power (+5V) | 120 W |
| Combined power (-12V) | 6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V) | 100 A |
| Max output current (+5V) | 20 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 3 A |
| Hold time | 20.42 ms |
| Efficiency | 92.7% |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Surge & inrush, Under voltage |
| Technical details | |
| Sustainability certificates | ENERGY STAR, ErP, Triman |
| Weight & dimensions | |
| Width | 150 mm |
| Depth | 160 mm |
| Height | 86 mm |
| Weight | 1.88 kg |
Questions & answers
What is the delivery time of Be quiet! BP030EU Power supply POWER ZONE 2 1200W Modular 80+ Platinum?
The article Be quiet! BP030EU Power supply POWER ZONE 2 1200W Modular 80+ Platinum is currently in stock
According to our experience the article is ready for dispatch within 9 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Be quiet! BP030EU to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Be quiet! BP030EU Power supply POWER ZONE 2 1200W Modular 80+ Platinum always at the best possible price. We can give you a discount of 2% on Be quiet! BP030EU Power supply POWER ZONE 2 1200W Modular 80+ Platinum if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
