Bals 85007 socket combinations Variabox M Mobil
|
766,42 EUR |
|||||||||||
|
incl. 4,71 EUR copper surcharge ( 912,04 EUR incl. VAT ) ≈ £641.49 | ≈ $857.62 plus delivery charges: 55,00 € |
|||||||||||
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |||||||||||
| Lieske Part No.: | 569621 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 85007 | ||||||||||
| UPC/EAN: | 4024941207171 | ||||||||||
| Weight: | 4.928 kg | ||||||||||
| Type: | 85007 | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Bals 85007:
Standard: DIN EN 61439-2
Protection class: IP44
Housing:
high-quality, impact-resistant plastic housing (PBT)
sealable, top section straight, cover screws
captive, safety elements arranged
under transparent operating flap with b
user-friendly OTC mechanism (one touch close)
distributor including carrying handle
Device color: lower housing section black similar to RAL 9017, upper housing section grey RAL 7035
Device height: 260 mm, device width: 230 mm, device depth: 145 mm
RDF factor: 0.68
InA: 32
Equipment:
2 x earthed socket 16A 230V blue IP44
1 x CEE socket 16A 400V 5p 6h IP44 inclined
Fuse/protective measure:
2 x C-automatic circuit breaker 16A 1p / make ABB
1 x C-automatic circuit breaker 16A 3p / make ABB
1 x residual current device 40/0.03A 4p / make ABB
mounted on a pull-out mounting rail
Cable entry/connection option:
CEE plug 32A 400V 5p 6h
with 2m H07RN-F5 G4 cable
Additional information:
Wired ready for connection
Construction according to Z-No. Z1202107
| General | |
| CEE socket outlet 16 A | 1x16A5p400V |
| CEE socket outlet 32 A | None |
| CEE socket outlet 63 A | None |
| CEE socket outlet 125 A | None |
| Number of socket outlets with protective contact | 2 |
| number of socket outlets swiss standard type 13 | 0 |
| number of socket outlets swiss standard type 15 | 0 |
| number of socket outlets swiss standard type 23 | 0 |
| number of socket outlets swiss standard type 25 | 0 |
| Other fixtures and/or empty locations | 0 |
| Protection | Over current switch |
| Earth leakage switch | Earth leakage switch with IFN 30 mA (standard) |
| Number of miniature circuit breakers | 3 |
| Material housing | Plastic |
| Power supply/connection possibility | Feeder cable with plug |
| Type of mains connection | CEE 32 A |
| Cable length | 2 |
| Handling | Portable |
| Degree of protection (IP) | IP44 |
| Colour | Grey |
| Height | 260 |
| Width | 230 |
| Depth | 145 |
| Military model | |
Questions & answers
What is the delivery time of Bals 85007 socket combinations Variabox M Mobil?
The article Bals 85007 socket combinations Variabox M Mobil is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Bals 85007 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Bals 85007 socket combinations Variabox M Mobil always at the best possible price. We can give you a discount of 2% on Bals 85007 socket combinations Variabox M Mobil if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 3 pieces of Bals 85007 socket combinations Variabox M Mobil we can offer you a price of 715,00 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
