Bals 28045 attachment plug TN straight 125A 5p 400V 6h IP67
|
1.205,03 EUR |
|||||||||||
|
( 1.433,99 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Lieske Part No.: | 389593 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 28045 | ||||||||||
| UPC/EAN: | 4024941280457 | ||||||||||
| Weight: | 0.12 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for BALS 28045:
125A 5p (3P+N+PE) 400V (200/346 - 240/415V~) 6h IP67
Frequency: 50/60Hz
Technical identification colour: bronze green RAL 6031-F9
Contact carrier/contacts: the contact carrier is made of highly heat-resistant material, the contacts are nickel-plated brass
Maximum conductor cross-section: 50.0 mm²
Housing material: polyamide
Connection technology: screw terminals as box terminals
Cable entry: other
Device colour: bayonet ring bronze green RAL 6031-F9, collar bronze green RAL 6031-F9, cover bronze green RAL 6031-F09, housing bronze green RAL 6031-F9, flange bronze green RAL 6031-F09
Device height: 126 mm, device width: 125 mm, device depth: 151 mm
Flange dimension vertical: 120 mm, flange dimension horizontal: 120 mm
Hole spacing vertical: 100 mm, hole spacing horizontal: 100 mm
Other technical properties: With cover cap
VG type no.: VG 96919 AP 013, supply no.: 5935-12-381-9980
