Bals 130278 mounting socket QC TE straight 16 A 5p >50 V 1 h IP44 grey W x H x D: 86 x 75 x 93
|
118,66 EUR |
|||||||||||
|
( 141,21 EUR incl. VAT ) ≈ £99.32 | ≈ $132.78 plus delivery charges: 55,00 € |
|||||||||||
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |||||||||||
| Lieske Part No.: | 468320 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 130278 | ||||||||||
| UPC/EAN: | 4024941938976 | ||||||||||
| Weight: | 0.148 kg | ||||||||||
| Type: | 130278 | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Bals 130278:
16A 5p (3P+N+PE) >50V grey (> 50V - All nominal voltages and/or frequencies not covered by other arrangements. This time setting can also be used in special applications where a distinction from standardized positions is required.) 1h IP44
Technical identification color: grey RAL 7035
Contact carrier/contacts: the contact carrier is made of highly heat-resistant material, the contacts are nickel-plated brass
Maximum conductor cross-section: 4.0 mm²
Housing material: polyamide
Connection technology: screwless spring clamp technology as cage clamp with Kontex contact
Cable entry: other
Device color: hinged cover grey RAL 7035, housing grey RAL 7035
Device height: 86 mm, device width: 75 mm, device depth: 93 mm
Flange dimension vertical: 75 mm, flange dimension horizontal: 75 mm
Hole spacing vertical: 60 mm, hole spacing horizontally: 60 mm
| General | |
| IEC-amperage | 16 |
| Voltage acc. EN 60309-2 | >50 V grey |
| Number of poles | 5 |
| Clock hour position | 1 |
| Identification colour | Grey |
| RAL-number | 7035 |
| Degree of protection (IP) | IP44 |
| Connection system | Screw less terminal |
| Angle of plug | Straight |
| Material | Plastic |
| Flange size vertical | 75 |
| Drill hole distance vertical | 60 |
| Flange size horizontal | 75 |
| Drill hole distance horizontal | 60 |
| Military model | |
Questions & answers
What is the delivery time of Bals 130278 mounting socket QC TE straight 16 A 5p >50 V 1 h IP44 grey W x H x D: 86 x 75 x 93?
The article Bals 130278 mounting socket QC TE straight 16 A 5p >50 V 1 h IP44 grey W x H x D: 86 x 75 x 93 is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Bals 130278 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Bals 130278 mounting socket QC TE straight 16 A 5p >50 V 1 h IP44 grey W x H x D: 86 x 75 x 93 always at the best possible price. We can give you a discount of 2% on Bals 130278 mounting socket QC TE straight 16 A 5p >50 V 1 h IP44 grey W x H x D: 86 x 75 x 93 if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 5 pieces of Bals 130278 mounting socket QC TE straight 16 A 5p >50 V 1 h IP44 grey W x H x D: 86 x 75 x 93 we can offer you a price of 112,43 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
