Bals 11919 wall socket QUICK-CONNECT 32A 3-pole 230V 6h IP44 enclosure size:92x94
|
89,02 EUR |
|||||||||||
|
( 105,93 EUR incl. VAT ) ≈ £74.51 | ≈ $99.61 plus delivery charges: 55,00 € |
|||||||||||
| Delivery time from supplier's stock (ca.) 2 workdaysinfo_outline | |||||||||||
| In Stock: 5 pieces | |||||||||||
| Lieske Part No.: | 837183 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 11919 | ||||||||||
| UPC/EAN: | 4024941119191 | ||||||||||
| Weight: | 0.28 kg | ||||||||||
| Type: | 11919 | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Bals 11919:
32A 3p (2P+PE) 230V (200 - 250V~) 6h IP44
Frequency: 50/60Hz
Technical identification colour: blue RAL 5015
Housing size: 92x94 mm (HxW)
Contact carrier/contacts: the contact carrier is made of polyamide, the contacts are bare brass
Maximum conductor cross-section: 10.0 mm²
Housing material: polyamide
Connection technology: screwless spring clamp technology as cage clamp with Kontex contact
Cable entry: 1xM25 at the top
Device colour: collar blue RAL 5015, hinged lid blue RAL 5015, housing base grey RAL 7035, housing top grey RAL 7035
Device height: 143 mm, device width: 94 mm, device depth: 103 mm
Other technical properties: The cable entry is open at the top and closed at the bottom
| General | |
| IEC-amperage | 32 |
| Number of poles | 3 |
| Voltage acc. EN 60309-2 | 230 V (50+60 Hz) blue |
| Clock hour position | 6 |
| Identification colour | Blue |
| RAL-number | 5015 |
| Degree of protection (IP) | IP44 |
| Connection system | Screw less terminal |
| Cable entry | Swivel |
| Material | Plastic |
| Type of fastening | External mounting |
| Mounting method | Surface mounted (plaster) |
| Insulated mounting | |
| Military model | |
| Lockable | |
| Text field | |
