Balluff BES0568 BES Q08ZC-GNX15B-EP02 inductive sensors content_copy

Inductive NAMUR sensors and switching amplifiers enable you to easily and contactlessly detect the status in sensitive areas. The sensors are placed inside the working area and the switching amplifier outside. This supports process stability. In addition to standard versions, we offer high-pressure variants, for example for end position monitoring in hydraulic cylinders or for position monitoring on valves. You can get explosion-proof variants for potentially explosive systems or rooms in Zones 1 and 2. Proven types are also available for applications in the semiconductor industry. Dimensions = 40 x 8 x 8 mm, design = 8x8, installation = flush, range = 1.5 mm, interface = NAMUR, switching frequency = 5000 Hz, housing material = zinc, die-cast, coated, active surface, material = PBT, connection = cable, 2.00 m, PUR, operating voltage Ub = 7.7...9 VDC, ambient temperature = -25...70 °C, protection class = IP67, approval/conformity = CE, cULus, WEEE
