Audiocodes Mediant 1000B Spare Part - RS-232 Console Cable Kit (10 units) content_copy

The Audiocodes M1KB-SERIAL-KIT is a replacement part for VoIP gateways, specifically designed for use with the Mediant 1000B model. It is a cable set serving as a console connection to enable device operation via a serial interface. The cables are black and feature an RS-232 connector at both ends, allowing connection to standard PC interfaces or terminal devices. The cable is typically used for configuration, maintenance, or diagnostics of the gateway via a serial console, establishing the physical connection through the cable.

Applications
This cable set is primarily intended for use in professional IT and telecommunications environments, particularly for the maintenance and configuration of VoIP gateways. It is used in network infrastructures where a direct serial connection to the device is required, such as during initialization, software updates, or troubleshooting. Compatibility is limited to the Mediant 1000B model, making it a specific replacement part.

Functions and Equipment in Detail
The M1KB-SERIAL-KIT consists of ten identical cables, each equipped with RS-232 connectors. This interface enables data transmission in serial form, with communication occurring over a single data line. The cables are typically used with a terminal emulator or a PC equipped with a corresponding serial interface. They are designed for use in IT networks where a stable, direct connection to the device is required.

Technology Explained Simply
The RS-232 interface is a widely used standard interface for serial communication, particularly in IT and telecommunications technology. It enables data transmission between two devices via a cable, with signals transmitted serially, bit by bit. The connection can be unidirectional or bidirectional, depending on configuration. The cables in the M1KB-SERIAL-KIT are optimized for use with the Mediant 1000B, with connectors matched to the gateway’s ports.

Compatibility and Accessories
The cable set is exclusively intended for the Audiocodes Mediant 1000B model. It serves as a replacement part and is not suitable for other gateways or devices. Use requires a device with an RS-232 interface compatible with the Mediant 1000B.

Installation and Mounting
Installation involves directly connecting the cable between the Mediant 1000B gateway and a terminal device, such as a PC with a serial interface. The connection is made via the RS-232 connectors, ensuring correct polarity and secure plug-in. Configuration is performed using a terminal program that supports serial communication. No special mounting instructions or tools are required for installation.

Operational Advantages
Using the M1KB-SERIAL-KIT enables a direct, stable connection to the gateway, independent of network connections. This is particularly advantageous during maintenance or troubleshooting when the device’s network connection is unavailable or impaired. The cables are supplied in a pack of ten units, facilitating preparation for multiple devices or replacement needs. The black color is neutral and fits typical IT environments.

Features
Product colour	Black
Connector 1	RS-232
Connector 2	RS-232
Compatible products	Mediant 1000B
Packaging data
Quantity per pack	10 pc(s)

---
