ATEN VE66DTH 6x6 Dante Audio Interface with HDMI content_copy

ATEN VE66DTH is a Dante-capable audio interface with six inputs and six outputs and HDMI. Using Dante ™, Audinate's most popular audio network solution, the VE66DTH is able to deliver uncompressed digital audio signals with near zero latency over your standard IP network. The VE66DTH sends and receives up to 6-channel audio inputs and outputs via a Dante network - the audio inputs can not only support the line input, but also dynamic and condenser microphones at the same time. In addition, the device can also supply condenser microphones with 48 V phantom power. With its integrated PoE (Power over Ethernet), the VE66DTH can be supplied with power from a compatible PSE device via an Ethernet cable. In addition, the VE66DTH offers flexible audio functions with audio de-embedding and embedding. It can de-embed HDMI stereo audio signals into the Dante network system and embed Dante audio signals into the HDMI output.
The VE66DTH is tailor-made for a variety of environments, such as: B. conference centers, concert halls, entertainment facilities or anywhere where the use of professional audio equipment based on Dante is required for advanced and flexible networked AV applications. VE66DTH users can benefit from improved system performance, reduced cabling and much more for installations of all sizes.
Scope of delivery:1x VE66DTH 6 x 6 Dante audio interface with HDMI
6x 5-pole connection blocks
4x footrests
1x KC06-0040-100G assembly set
1x 0AD8-1F05-30M1 power supply
1x User guides

Inputs
HDMI in	1
DC-in jack
Logistics data
Master (outer) case net weight	5.5 kg
Harmonized System (HS) code	85176990
Master (outer) case width	232 mm
Master (outer) case length	500 mm
Master (outer) case height	283 mm
Master (outer) case gross weight	6.95 kg
Products per master (outer) case	5 pc(s)
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 80%
Storage relative humidity (H-H)	0 - 80%
Outputs
Number of HDMI outputs	1
Packaging data
Quantity	1
Package width	95 mm
Package depth	265 mm
Package height	220 mm
Package weight	1.26 kg
Power
Power consumption (typical)	8.9 W
Operating voltage	5 V
External power adapter
Technical data
Inputs x outputs	6x6
Article type	Dante audio interface
Packaging volume	0.0069m³
Interface	5-pin terminal blocks + HDMI
Weight	1.260kg
Height packaging	0.220m
Length packaging	0.265m
Width packaging	0.095m
Technical details
Maximum transfer distance	1.8 m
Product colour	Black
Maximum resolution	4096 x 2160 pixels
Housing material	Metal
Weight & dimensions
Width	174.2 mm
Depth	154.9 mm
Height	28.8 mm
Weight	1.1 kg

---
