Aten KVM extender, over IP, (T+R), DVI-D
|
2.671,68 EUR |
|
|
( 3.179,30 EUR incl. VAT ) ≈ £2,249.55 | ≈ $3,000.30 plus delivery charges: 53,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1289690 |
| Mfg Part No: | KE6910 |
| UPC/EAN: | 4719264648267 |
| Weight: | 2 kg |
Product information for Aten KE6910:
*Order based, Non-Cancellable*, Supports video resolutions up to 2560 x 2048 @ 50 Hz, including resolutions of 2560 x 1600 @ 60 Hz and 2048 x 2048 @ 60 Hz Adaptive Fast Switching automatic fast switching between different Tx video resolutions on an Rx monitor Within 0.3 seconds push and pull content immediately with just one click Release supports power redundancy with dual DC sockets Scope of delivery 1 x KE6910T 2K DVI-D Dual Link KVM over IP transmitter 1 x KE6910R 2K DVI-D Dual Link KVM over IP receiver 2 x 0AD8-8005-40MA power supply 2 x LIN2-418K-E12G power cable 1 x LIN5-36W1-W11G KVM cable (DVI-D dual-link, USB, audio 1.8 m/6 ft) 1 x foot support set (4 pcs.) 1 x assembly kit 1 x user manual
| Features | |
| Type | Transmitter & receiver |
| Connectivity technology | Wired |
| Maximum transfer distance | 10000 m |
| Cable types supported | Cat5 |
| Maximum digital resolution | 2560 x 2048 pixels |
| KVM port selection | Push-buttons |
| Product colour | Black |
| Material | Metal |
| Certification | RoHS |
| Rack mounting | |
| On Screen Display (OSD) | |
| LED indicators | |
| Logistics data | |
| Master (outer) case net weight | 3.62 kg |
| Harmonized System (HS) code | 84733080 |
| Master (outer) case width | 247 mm |
| Master (outer) case length | 556 mm |
| Master (outer) case height | 153 mm |
| Master (outer) case gross weight | 4.61 kg |
| Products per master (outer) case | 1 pc(s) |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Packaging content | |
| Cables included | AC, KVM |
| AC adapter included | |
| Manual | |
| Packaging data | |
| Package width | 247 mm |
| Package depth | 556 mm |
| Package height | 153 mm |
| Package weight | 4.61 kg |
| Ports & interfaces | |
| USB port type | USB Type-A |
| USB 2.0 ports quantity | 4 |
| RS-232 ports | 2 |
| RJ-45 ports quantity | 2 |
| PC Audio in | |
| PC Audio out | |
| Power | |
| AC adapter output voltage | 5 V |
| Power consumption (transmitter) (max) | 10.02 W |
| Power consumption (receiver) (max) | 9.02 W |
| Receiver | |
| Receiver local video port type | DVI-D |
| Receiver local keyboard/mouse port type | USB |
| RJ-45 ports quantity (receiver) | 1 |
| Technical details | |
| Weight | 3.62 kg |
| Transmitter | |
| Transmitter video port type | DVI-D |
| Transmitter local video port type | DVI-D |
| Transmitter local keyboard/mouse port type | USB |
| RJ-45 ports quantity (transmitter) | 1 |
| Transmitter local video port | |
| Weight & dimensions | |
| Transmitter width | 16.3 cm |
| Transmitter depth | 21.5 cm |
| Transmitter height | 4.18 cm |
| Transmitter weight | 1.13 kg |
| Receiver width | 17.2 cm |
| Receiver depth | 22.8 cm |
| Receiver height | 5.48 cm |
| Receiver weight | 1.26 kg |
Questions & answers
What is the delivery time of Aten KVM extender, over IP, (T+R), DVI-D?
The article Aten KVM extender, over IP, (T+R), DVI-D is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Aten KE6910 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Aten KVM extender, over IP, (T+R), DVI-D always at the best possible price. We can give you a discount of 2% on Aten KVM extender, over IP, (T+R), DVI-D if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
