ATEN KA8288 Dual HDMI KVM Console Station over IP
|
1.046,79 EUR |
|
|
( 1.245,68 EUR incl. VAT ) ≈ £881.40 | ≈ $1,175.55 plus delivery charges: 53,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1368521 |
| Mfg Part No: | KA8288 |
| UPC/EAN: | 4719264647000 |
| Weight: | 1.315 kg |
Product information for Aten KA8288:
*Order based order*
| Features | |
| Type | AV transmitter & receiver |
| Maximum resolution | 1920 x 1200 pixels |
| Material | Metal |
| Product colour | Black |
| Compatible products | CS72D,CS1642A,CS1184,CS1782A,CS1784A,CM0264,CS1762A,CS1764A,CS1732B,CS1734B,KL1516Ai,CL6700,CM1164,CS1308,CS1732A,CE604,CS1734A,CS1708A,CS22D,CL5716,CS682,KN4140v,KL3116,2L-7D02UI,CE750,2L-7D03UI,2L-7D02U,CCKM,2L-7D03U,CS62U,2L-7D05U,UC10KM,CL5716M,CL5716N,2X-021G,2X-031G,2L-7DX2U,2L-7DX3U,ES0152,ES0152P,CL3884NW |
| LED indicators | |
| Logistics data | |
| Master (outer) case width | 247 mm |
| Master (outer) case length | 556 mm |
| Master (outer) case height | 153 mm |
| Master (outer) case gross weight | 4.61 kg |
| Master (outer) case net weight | 3.76 kg |
| Products per master (outer) case | 1 pc(s) |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Packaging content | |
| Packaging content | 1x KE6900T DVI KVM Over IP Extender (Transmitter) 1x KE6900R DVI KVM Over IP Extender (Receiver) 2x 0AD8-8005-40MG Power Adapters 2x LIN2-418K-E12G Power Cord 1x 2L-7D02U USB DVI-D KVM Cable (1.8m) 1x Mounting Kit for KE6900T 1x Mounting Kit for KE6900T 1x User Instructions |
| AC adapter included | |
| Packaging data | |
| Package width | 247 mm |
| Package depth | 556 mm |
| Package height | 153 mm |
| Package weight | 4.61 kg |
| Ports & interfaces | |
| Connectivity technology | Wired |
| RJ-45 input ports | 2 |
| DVI input ports | 1 |
| DVI output ports | 2 |
| USB ports quantity | 6 |
| USB version | 2.0 |
| USB connector type | USB Type-A, USB Type-B |
| RS-232 input ports | 2 |
| Audio input | 2 |
| Audio output | 2 |
| Serial ports quantity | 3 |
| Serial interface type | RS-232 |
| Ethernet LAN | |
| DC-in jack | |
| Power | |
| Operating voltage (transmitter) | 5 V |
| Operating voltage (receiver) | 5 V |
| Power consumption (transmitter) (max) | 7.34 W |
| Power consumption (receiver) (max) | 6.9 W |
| Technical details | |
| Country of origin | Taiwan |
| Weight & dimensions | |
| Receiver dimensions (WxDxH) | 227.5 x 171.6 x 54.8 mm |
| Receiver weight | 1.25 kg |
| Transmitter dimensions (WxDxH) | 215 x 162.9 x 45.6 mm |
| Transmitter weight | 1.14 kg |
Questions & answers
What is the delivery time of ATEN KA8288 Dual HDMI KVM Console Station over IP?
The article ATEN KA8288 Dual HDMI KVM Console Station over IP is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Aten KA8288 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you ATEN KA8288 Dual HDMI KVM Console Station over IP always at the best possible price. We can give you a discount of 2% on ATEN KA8288 Dual HDMI KVM Console Station over IP if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
