Aten CS1924M 4-Port USB 3.0 4K DisplayPort MST KVM Switch

Your rating:
Average rating
product review for Aten CS1924M 4-Port USB 3.0 4K DisplayPort MST KVM Switch
( 4.8 / 5 ) 9 ratings
Aten CS1924M
This image may differ from the desired article.
Aten CS1924MAten CS1924MAten CS1924MAten CS1924MAten CS1924MAten CS1924MAten CS1924MAten CS1924MAten CS1924M
-20% 294,88 EUR 370,50 EUR
( 350,91 EUR incl. VAT )
≈ £245.64  |  ≈ $323.48
plus delivery charges: 55,00 €
Delivery time from supplier's stock (ca.) 6 workdaysinfo_outline
In Stock: >5 pieces
1x Aten CS1924M 4-Port USB 3.0 4K DisplayPort MST KVM Switch
Datasheet:file_download Download
Lieske Part No.:1484001
Mfg Part No: CS1924M
UPC/EAN: 4719264645839
Weight:2.579 kg

Product information for Aten CS1924M:

*Order-based, non-cancellable* The CS1924M 4-Port USB 3.0 4K DisplayPort MST KVMP Switch is the world's first DisplayPort KVM switch with a built-in MST hub that uses the latest Multi-Stream Transport (MST) technology. The CS1924M allows users to use two console displays from a single DisplayPort 1.2 video source. It offers extended desktop mode and splitter mode with resolutions up to 4K for dual-screen multitasking while reducing bulky cable connections.
To meet the ever-increasing demand for fast peripheral data transfers, the CS1924M integrates a USB 3.1 Gen 1 hub that enables unprecedented data transfer rates of up to 5Gbps, allowing you to maximize your multitasking operations.
The unique independent switching feature allows the KVM switch to focus on one computer while the USB peripherals focus on another computer. This eliminates the need to purchase a separate USB hub or individual peripheral, such as a print server or splitter. In addition, the switch allows sharing the audio signal from each of the connected computers and even transmits HD audio via a DisplayPort source.
With a rich feature set, the CS1924M is designed to exceed the requirements such as excellent video quality and ultra-fast data transfer speed for gaming, graphic design, animation and video editing programs

Design
Product colourBlack
Housing materialMetal, Plastic
LED indicatorsYes
Push buttonYes
Hot keysYes
Display
Built-in displayNo
Logistics data
Master (outer) case net weight10.1 kg
Harmonized System (HS) code85176200
Master (outer) case width342 mm
Master (outer) case length512 mm
Master (outer) case height232 mm
Master (outer) case gross weight13.7 kg
Products per master (outer) case5 pc(s)
Operational conditions
Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%
Storage relative humidity (H-H)0 - 80%
Packaging content
Quick installation guideYes
ManualYes
Packaging data
Package width98 mm
Package depth325 mm
Package height210 mm
Package weight2.56 kg
Performance
HD type4K Ultra HD
Maximum resolution4096 x 2160 pixels
Video bandwidth60 Hz
Scan interval1,5,99 s
Ports & interfaces
Number of computers controlled4
Keyboard port typeUSB
Mouse port typeUSB
Video port typeHDMI
DisplayPorts quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity2
Console ports3.5mm headphone, 3.5mm mic, DisplayPort, HDMI, USB A
Console USB ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity2
USB connector typeUSB Type-A, USB Type-B
Headphone outputs6
Number of microphone inputs6
USB hubYes
Audio connectionsYes
DC-in jackYes
Power
Power sourceDC
Input voltage5 V
Power consumption (typical)4.89 W
System requirements
Windows operating systems supportedYes
Technical data
Type 24-fold DisplayPort KVM
Height packaging0.210m
Data rate5Gb/s
Number of CPU4
Width packaging0.098m
Type 1KVM switch
Length packaging0.325m
Packaging volume0.0067m³
DesignDesktop
Weight2.563kg
Max. resolution4096x2160 / 60Hz
Video inputs per CPUDisplayPort x1
USB specificationUSB 3.2 Gen.1
DisplayPort standard1.2
USB peripheralsYes
Front panel buttonsYes
Incl. KVM cablesetYes
Weight & dimensions
Width270 mm
Depth88 mm
Height55.5 mm
Weight2.01 kg


Product data sheet
Datasheet for Aten CS1924M, EAN: 4719264645839

Questions & answers

What is the delivery time of Aten CS1924M 4-Port USB 3.0 4K DisplayPort MST KVM Switch?

The article Aten CS1924M 4-Port USB 3.0 4K DisplayPort MST KVM Switch is currently in stock

According to our experience the article is ready for dispatch within 6 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Aten CS1924M to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you Aten CS1924M 4-Port USB 3.0 4K DisplayPort MST KVM Switch always at the best possible price. We can give you a discount of 2% on Aten CS1924M 4-Port USB 3.0 4K DisplayPort MST KVM Switch if you choose payment in advance on ordering.

We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
