Aten CS1922M 2-Port USB 3.0 4K DisplayPort MST KVM Switch

Your rating:
Average rating
product review for Aten CS1922M 2-Port USB 3.0 4K DisplayPort MST KVM Switch
( 4.2 / 5 ) 9 ratings
Aten CS1922M
This image may differ from the desired article.
Aten CS1922MAten CS1922MAten CS1922MAten CS1922MAten CS1922MAten CS1922MAten CS1922MAten CS1922MAten CS1922M
-52% 188,58 EUR 394,86 EUR
( 224,41 EUR incl. VAT )
≈ £157.09  |  ≈ $206.87
plus delivery charges: 55,00 €
Delivery time from supplier's stock (ca.) 9 workdaysinfo_outline
In Stock: >25 pieces
1x Aten CS1922M 2-Port USB 3.0 4K DisplayPort MST KVM Switch
Datasheet:file_download Download
Lieske Part No.:1483983
Mfg Part No: CS1922M
UPC/EAN: 4719264645822
Weight:2 kg

Product information for Aten CS1922M:

*Order based, non-refundable* Computer selection via front panel pushbuttons, shortcut keys and mouse* Independent switching of KVM, USB and audio focus Superior video quality 4K UHD (3840 x 2160 at 60 Hz) and 4K DCI (4096 x 2160 at 60 Hz) 2- Port USB 3.1 Gen 1 Hub with SuperSpeed 5 Gbps data transfer rates DisplayPort 1.2 compatible, HDCP compatible Supports HD Audio via DisplayPort Full bass reproduction for high-quality 2.1 channel surround sound systems Power-on detection When a computer is switched off, the CS1922 automatically switches to the next switched-on computer Multi-Stream Transport (MST) enables multiple monitors via a single DisplayPort connection* Dual-mode DisplayPort technology (DP++) supports HDMI and DVI signals via a DisplayPort to HDMI/DVI DP++ adapter Hot pluggable computer without shutting down the switch add or remove Keyboard emulation/bypass function supports most gaming keyboards Mouse emulation/bypass function supports most mouse drivers and multifunction mice Multi-platform support Windows, Mac and Linux Multilingual keyboard layout supports English, Japanese, French and German keyboards Mac keyboard support and emulation *Automatic scanning mode for monitoring all computers

Design
Product colourBlack
Housing materialMetal, Plastic
LED indicatorsYes
Push buttonYes
Hot keysYes
Display
Built-in displayNo
Logistics data
Master (outer) case net weight2.8 kg
Harmonized System (HS) code85176200
Master (outer) case width292 mm
Master (outer) case length517 mm
Master (outer) case height194 mm
Master (outer) case gross weight9.85 kg
Products per master (outer) case5 pc(s)
Operational conditions
Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%
Storage relative humidity (H-H)0 - 80%
Packaging content
Quick installation guideYes
ManualYes
Packaging data
Package width100 mm
Package depth283 mm
Package height173 mm
Package weight1.84 kg
Performance
HD type4K Ultra HD
Maximum resolution4096 x 2160 pixels
Video bandwidth60 Hz
Scan interval1,5,99 s
Firmware upgradeableYes
Ports & interfaces
Number of computers controlled2
Keyboard port typeUSB
Mouse port typeUSB
Video port typeDisplayPort
DisplayPorts quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity2
Console ports3.5mm headphone, 3.5mm mic, DisplayPort, HDMI, USB A
Console USB ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity2
USB connector typeUSB Type-A, USB Type-B
Headphone outputs4
Number of microphone inputs4
USB hubYes
Audio connectionsYes
DC-in jackYes
Power
Power sourceDC
Input voltage5 V
Power consumption (typical)4.09 W
Technical data
Number of CPU2
Video inputs per CPUDisplayPort x1
USB specificationUSB 3.2 Gen.1
Max. resolution4096x2160 / 60Hz
Height packaging0.173m
Length packaging0.283m
DisplayPort standard1.2
Packaging volume0.0049m³
Weight1.874kg
Data rate5Gb/s
Type 22-fold DisplayPort KVM
Type 1KVM switch
Width packaging0.100m
DesignDesktop
Front panel buttonsYes
USB peripheralsYes
Incl. KVM cablesetYes
Weight & dimensions
Width210 mm
Depth88 mm
Height55.5 mm
Weight560 g


Product data sheet
Datasheet for Aten CS1922M, EAN: 4719264645822
