ATEN CS1182D 2-Port USB DVI Secure KVM Switch
|
-25% 287,28 EUR 383,97 EUR |
|
|
( 341,86 EUR incl. VAT ) ≈ £241.89 | ≈ $322.62 plus delivery charges: 53,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| End-Of-Life: | 15. Aug 2026 |
|---|---|
| Datasheet: | file_download Download |
| Lieske Part No.: | 1109228 |
| Mfg Part No: | CS1182D-AT |
| UPC/EAN: | 4719264646515 |
| Weight: | 2.5 kg |
Product information for Aten CS1182D-AT:
*Order based, non-cancellable* Compliant with PSS PP v3.0 (Protection Profile for Peripheral Sharing Switch, Version 3.0) Security requirements Permanent housing Intrusion detection renders the ATEN PSS PP v3.0 Secure KVM Switches unusable if physical tampering is detected Configurable USB device filtering CAC Port can be configured to allow or deny whitelisted or blacklisted devices via the admin login function or a Windows-based application Superior video quality up to 4K (3840 x 2160 at 30 Hz), 2560 x 1600 (DVI -Dual-Link), 1920 x 1200 (DVI-Single-Link) and 2048 x 1536 (DVI-A) Scope of delivery 1x CS1182D 2-Port USB DVI Secure KVM Switch 1x LIN2-418K-E12G power cable 1x user manual
| Design | |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | |
| Push button | |
| Display | |
| Built-in display | |
| Logistics data | |
| Master (outer) case net weight | 6 kg |
| Harmonized System (HS) code | 85176200 |
| Master (outer) case width | 375 mm |
| Master (outer) case length | 565 mm |
| Master (outer) case height | 258 mm |
| Master (outer) case gross weight | 8.47 kg |
| Products per master (outer) case | 3 pc(s) |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Packaging content | |
| Cables included | AC |
| Quick installation guide | |
| Manual | |
| Packaging data | |
| Package width | 116 mm |
| Package depth | 540 mm |
| Package height | 233 mm |
| Package weight | 2.51 kg |
| Performance | |
| HD type | 4K Ultra HD |
| Maximum resolution | 3840 x 2160 pixels |
| Video bandwidth | 30 Hz |
| Ports & interfaces | |
| Number of computers controlled | 2 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DVI-I |
| DVI-I ports quantity | 2 |
| USB 2.0 Type-B ports quantity | 4 |
| Console ports | 3.5mm headphone, DVI-I, PS/2, USB A |
| Console USB ports quantity | 2 |
| USB connector type | USB Type-B |
| Headphone outputs | 3 |
| Audio connections | |
| Power | |
| Power source | AC |
| Input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 1 A |
| Power consumption (typical) | 4.4 W |
| Sustainability | |
| Compliance certificates | RoHS |
| System requirements | |
| Windows operating systems supported | |
| Weight & dimensions | |
| Width | 335 mm |
| Depth | 164.3 mm |
| Height | 44 mm |
| Weight | 2 kg |
