ATEN CS1762A KVM Switch DVI USB Audio USB Hub 2 Ports
|
126,43 EUR |
|
|
( 150,45 EUR incl. VAT ) ≈ £105.57 | ≈ $141.73 plus delivery charges: 55,00 € |
|
| Delivery time from supplier's stock (ca.) 3 workdaysinfo_outline | |
| In Stock: >10 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 436195 |
| Mfg Part No: | CS-1762 |
| UPC/EAN: | 4710423776821 |
| Weight: | 2.04 kg |
Product information for Aten CS-1762:
Device Type: KVM / audio switch - 2 ports, Type: Desktop, Ports: 2 x KVM / audio, Num. KVM Local Users: 1 local user, keyboard / mouse interface: USB, Max Resolution: 1920 x 1200, features: Built-in Hi-Speed ??USB Hub with 2 ports, Built-in Devices: USB Hub, Interfaces: Display / video: 2 x DVI / D - 29 pin combined DVI | USB: 2 x USB Type B, 4-pole | Audio: 2 x mini-phone stereo 3.5 mm | Display / Video: 1 x DVI-Analogue / Digital - 29 pin combined DVI | Keyboard: 1 x USB - USB Type A 4-pin | Mouse: 1 x USB - USB Type A 4-pin, Power Device: Power adapter - external Width: 21 cm, depth: 8.7 cm, height: 5.5 cm, Weight: 0.73 kg, Cables Included: 2 x keyboard / mouse / video cable Compliant Standards: RoHS, OS Required: Apple MacOS, SunOS, Linux, Microsoft Windows, Operating Temperature Min: 0 ° C, Max. Operating temperature: 50 ° C, Humidity Range Operating: 0 - 80% (non-condensing), Min. Storage temperature: -20 ° C, Max. Storage temperature: 60 ° C
| Design | |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | |
| Push button | |
| Hot keys | |
| Display | |
| Built-in display | |
| Logistics data | |
| Master (outer) case net weight | 6.9 kg |
| Harmonized System (HS) code | 85176200 |
| Master (outer) case width | 292 mm |
| Master (outer) case length | 517 mm |
| Master (outer) case height | 194 mm |
| Master (outer) case gross weight | 8.65 kg |
| Products per master (outer) case | 5 pc(s) |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% |
| Packaging content | |
| Quick installation guide | |
| Manual | |
| Packaging data | |
| Package width | 100 mm |
| Package depth | 283 mm |
| Package height | 173 mm |
| Package weight | 1.63 kg |
| Performance | |
| HD type | WUXGA |
| Maximum resolution | 1920 x 1200 pixels |
| Video bandwidth | 60 Hz |
| Scan interval | 1,99 s |
| DDC2B support | |
| Ports & interfaces | |
| Number of computers controlled | 2 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DVI-I |
| DVI-I ports quantity | 2 |
| USB 2.0 Type-B ports quantity | 2 |
| Console ports | 3.5mm headphone, 3.5mm mic, DVI-I, USB A |
| Console USB ports quantity | 2 |
| USB connector type | USB Type-A, USB Type-B |
| Headphone outputs | 3 |
| Number of microphone inputs | 3 |
| Audio connections | |
| DC-in jack | |
| Power | |
| Power source | DC |
| Input voltage | 5.3 V |
| Power consumption (typical) | 3.78 W |
| Technical data | |
| Data rate | 480Mb/s |
| Video inputs per CPU | DVI-D (Single Link) x1 |
| Design | Desktop |
| Weight | 1.629kg |
| Length packaging | 0.283m |
| Type 2 | 2-fold DVI KVM |
| USB specification | USB 2.0 |
| Height packaging | 0.173m |
| Width packaging | 0.100m |
| Type 1 | KVM switch |
| Max. resolution | 1920x1200 / 1080p |
| Packaging volume | 0.0049m³ |
| Number of CPU | 2 |
| USB peripherals | |
| Front panel buttons | |
| Incl. KVM cableset | |
| Weight & dimensions | |
| Width | 210 mm |
| Depth | 88 mm |
| Height | 55.5 mm |
| Weight | 1.38 kg |
Questions & answers
What is the delivery time of ATEN CS1762A KVM Switch DVI USB Audio USB Hub 2 Ports?
The article ATEN CS1762A KVM Switch DVI USB Audio USB Hub 2 Ports is currently in stock
According to our experience the article is ready for dispatch within 3 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Aten CS-1762 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you ATEN CS1762A KVM Switch DVI USB Audio USB Hub 2 Ports always at the best possible price. We can give you a discount of 2% on ATEN CS1762A KVM Switch DVI USB Audio USB Hub 2 Ports if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
