ARCTIC Kühler Freezer 4U-M CPU Cooler for AMD socket SP3 content_copy

The ARCTIC Freezer 4U-M Rev. 2 is a high-performance 4U server cooler, specifically designed for use in server and workstation environments with high demands for reliability, efficiency, and longevity. It is compatible with processors from AMD and Intel, including modern sockets such as LGA 4189, LGA 4677 (Socket E), LGA 4710 (Socket E2), SP6, Socket TR4, TR5, sTRX4, and socket sWRX8. With a Thermal Design Power (TDP) of 350 W, it ensures effective heat dissipation under heavy loads, making it ideal for powerful server systems. The cooling unit features 8 heat pipes with a diameter of 6 mm and an aluminum fin heatsink with 57 fins, enabling optimal heat distribution and dissipation. Two 12-cm fans with dual ball bearings ensure stable, quiet operation and a long lifespan—the maximum noise level is only 40 dB, while the airflow of 122.16 m³/h (equivalent to 71.9 cfm) provides efficient cooling. The fans are controlled via a 4-pin connector, allowing for precise speed regulation. The compact design, with a height of 145 mm and a width of 156 mm, fits perfectly into standard 4U rack systems. The cooler is made of aluminum and black and offers a robust, durable construction for continuous operation in professional IT environments.

Design
Product colour	Aluminium, Black
Number of fans	2 fan(s)
Number of fins	57
Fins material	Aluminium
Number of heat pipes	8
Fan connector	4-pin
Rack capacity	4U
Display type	Not applicable
Illumination LED
Packaging content
Package type	Box
Performance
Suitable location	Processor
Type	Air cooler
Fan diameter	12 cm
Supported processor sockets	LGA 4189, LGA 4677 (Socket E), LGA 4710 (Socket E2), SP6, Socket TR4, Socket TR5, Socket sTRX4, Socket sWRX8
Maximum airflow	71.9 cfm
Airflow	122.16 m³/h
Bearing type	Dual ball bearing
Fan noise level (max)	40 dB
Fan speed (min)	400 RPM
Fan speed (max)	2300 RPM
Fan static pressure	3.3 mmH2O
Operating temperature (T-T)	0 - 40 °C
Power
Starting voltage	8 V
Thermal Design Power (TDP)	350 W
Fan voltage	12 V
Fan current	0.12 A
Weight & dimensions
Width	156 mm
Depth	124 mm
Height	145 mm
Weight	1.27 kg
Heat pipes diameter	6 mm
Cable length	0.2 m
Package width	160 mm
Package depth	211 mm
Package height	141 mm
Package weight	1.55 kg

---
