AMD 100-100001973WOF Ryzen 7 9850X3D 5.6 GHz AM5 104 Mainboard Cache content_copy

This item is a processor from the AMD Ryzen 7 9850X3D series, designed for use in desktop computers with AM5 socket. This CPU type is part of the Ryzen 7000 generation and is based on the Zen-4 architecture. It is designed for users requiring high computing performance combined with energy efficiency, particularly in areas such as gaming, multimedia production, or performance-intensive applications in office and home environments.

Applications
This processor is suitable for systems requiring high clock speeds and a balanced core/thread configuration. It is particularly suited for applications relying on fast single-thread performance, such as modern games, video editing software, or applications with high memory requirements. Support for DDR5 memory with a maximum speed of 5600 MHz enables efficient data processing. The CPU is designed for use in standard PCs with AM5 socket, not for workstation systems with sWRX9 socket.

Features and Specifications in Detail
The processor features 8 cores and 16 threads, enabling parallel processing of multiple tasks. The base clock frequency is 4.7 GHz, with a boost clock reaching up to 5.6 GHz, depending on load and cooling conditions. The integrated cache technology includes 104 MB of L3 cache, allowing faster access to frequently used data. This enhances overall performance, especially in applications requiring fast access to large data sets. The CPU supports 28 PCIe 5.0 slots, 24 of which are available for external components.

Technology Explained Simply
The Zen-4 architecture, on which the processor is based, offers improved transistor performance and more efficient data processing. The use of DDR5 memory up to 5600 MHz enables faster data transfer between CPU and RAM. PCIe 5.0 support ensures high bandwidth for graphics cards, NVMe SSDs, and other fast peripheral devices. The TDP (Thermal Design Power) is 120 W, indicating maximum heat output under load and relevant for selecting appropriate cooling.

Compatibility and Accessories
The processor is compatible exclusively with motherboards featuring AM5 socket. It requires a motherboard supporting the Zen-4 architecture and DDR5 memory. The CPU is not intended for systems with sWRX9 socket, which are designed for workstation processors such as the Ryzen Threadripper PRO series. A suitable CPU cooler is required for operation to ensure adequate heat dissipation at the 120 W TDP. A motherboard with integrated memory controller for DDR5-5600 MHz is necessary to fully utilize memory performance.

Installation and Mounting
Installation involves placing the processor into the AM5 socket on the motherboard. Correct alignment of the CPU (e.g., via markings or pin layout) must be ensured. After insertion, the socket is locked. Since the processor is delivered without a cooler, an external CPU cooler must be installed before the system is put into operation. Mounting should follow the manufacturer’s instructions for the motherboard.

Advantages in Operation
The high base and boost clock frequencies ensure fast response times for applications relying on single-thread performance. The large 104 MB L3 cache improves access speed to frequently used data. Support for DDR5-5600 MHz and PCIe 5.0 enables a modern, high-performance system architecture.

General
Socket	AM5
Cores	8
Threads	16
Base clock	4,7 GHz
Turbo clock	5,6 GHz
L3 cache	104 MB
TDP	120 W
Memory support	DDR5-5600MHz
PCIe support	28x PCIe 5.0
Scope of delivery	Without cooler
Architecture	Zen-4

---
