ALLNET PoE Splitter Mini/Extractor / Gigabit / 24W / 5V/12V Switchable / ALL-PS102G-AF-AT
|
15,38 EUR |
|||||||||||
|
( 18,30 EUR incl. VAT ) ≈ £12.95 | ≈ $17.27 plus delivery charges: 53,00 € |
|||||||||||
| Delivery time from supplier's stock (ca.) 4 workdaysinfo_outline | |||||||||||
| In Stock: >100 pieces | |||||||||||
| Datasheet: | file_download Download | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Lieske Part No.: | 1970184 | ||||||||||
| Mfg Part No: | ALL-PS102G-AF-AT | ||||||||||
| UPC/EAN: | 4038816210357 | ||||||||||
| Weight: | 0.1 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Allnet ALL-PS102G-AF-AT:
ALLNET PoE Splitter-Mini/Extractor / Gigabit / 24W / 5V/12V Switchable / ALL-PS102G-AF-AT non-isolated Gigabit PD PoE splitter supports IEEE802.3af/at standard, compatible with PIN 12/36 82% efficiency , 2KV port protection isolation. It has short circuit, over current and over temperature protection. Plug and play, no configuration, easy to use.
Technical Details: Model ALL-PS102G-AF-AT Interface Characteristics Fixed Port 2x10/100/1000Base-T RJ45 ports (Data)
1*DC5521 power socket(Power) Ethernet Port Ethernet port can support 10/100/1000Base-T auto- sensing, full/half duplex MDI/MDI-X self-adaption Network Characteristics Transmission Bandwidth (Rate) 10/100/1000Mbps Twisted Pair Transmission 10BASE-T: Cat3,4,5 UTP(=100 meters)
100BASE-TX: Cat5 or later UTP(=100 meters)
1000BASE-T:Cat5e or later UTP(=100 meters) Output VoltageSwitch 12V: DC12Voutput voltage (default) 5V: DC5Voutput voltage Network Protocol and Indicator Network Protocol IEEE802.3 10BASE-T, IEEE802.3i 10Base -T
IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T
IEEE802.3x LED Indicator PoE indicator: POE (green), Power indicator: PWR (green) PoE Physical Parameter Operation TEMP / Humidity -20~+55°C, 5%~90% RH Non condensing Storage TEMP / Humidity -40~+85°C, 5%~95% RH Non condensing Dimension (L*W*H) 103*50*29mm Net /Gross Weight < /< Lightning protection / protection level Lightning protection: 4KV 8/20us Protection level: IP30 Marks CE
Technical Details: Model ALL-PS102G-AF-AT Interface Characteristics Fixed Port 2x10/100/1000Base-T RJ45 ports (Data)
1*DC5521 power socket(Power) Ethernet Port Ethernet port can support 10/100/1000Base-T auto- sensing, full/half duplex MDI/MDI-X self-adaption Network Characteristics Transmission Bandwidth (Rate) 10/100/1000Mbps Twisted Pair Transmission 10BASE-T: Cat3,4,5 UTP(=100 meters)
100BASE-TX: Cat5 or later UTP(=100 meters)
1000BASE-T:Cat5e or later UTP(=100 meters) Output VoltageSwitch 12V: DC12Voutput voltage (default) 5V: DC5Voutput voltage Network Protocol and Indicator Network Protocol IEEE802.3 10BASE-T, IEEE802.3i 10Base -T
IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T
IEEE802.3x LED Indicator PoE indicator: POE (green), Power indicator: PWR (green) PoE Physical Parameter Operation TEMP / Humidity -20~+55°C, 5%~90% RH Non condensing Storage TEMP / Humidity -40~+85°C, 5%~95% RH Non condensing Dimension (L*W*H) 103*50*29mm Net /Gross Weight < /< Lightning protection / protection level Lightning protection: 4KV 8/20us Protection level: IP30 Marks CE
