Allnet ALL-CAB-KV-01-L Installation cable gland M25x1.5 black IP68 long content_copy

The cable gland ALL-CAB-KV-01-L from Allnet is a robust component for secure and tight fixation of cables in electrical and network installations. It is specifically designed for use in environments with high requirements for protection against dust, water, and mechanical stress. The gland features a metric thread connection M25 x 1.5 in accordance with EN60423, enabling secure mounting on compatible devices or enclosures. Its material consists of halogen-free nylon PA 66, which has flame retardancy according to UL 94V-0, making it suitable for use in safety-critical installations. The surface is UV-resistant and designed for long service life, making it particularly suitable for outdoor use or installations exposed to sunlight.

Applications
The cable gland is suitable for use in industrial installations, outdoor environments, and network infrastructures where high mechanical and environmental resistance is required. It is frequently used in electrical installations, mounting of network devices, or in automation technology. The protection rating IP68 at a pressure of 0.1 Bar ensures complete sealing against dust and water, including submersion under low pressure. This makes it particularly suitable for applications in moist or wet environments, such as in agriculture, machine building, or manufacturing technology.

Functions and Equipment in Detail
The gland is available in the colour RAL9005 Black, providing good visibility and optical harmonization with other black components. The use of a silicone rubber ring ensures reliable sealing and prevents ingress of moisture or dirt. The elongated design enables better cable routing and reduces mechanical stress on the cable.

Technology Explained Simply
The protection rating IP68 means the gland is dust-tight and protected against water pressure up to 0.1 Bar. This corresponds to submersion under low pressure, making it suitable for use in wet or damp environments. The material PA 66 is a high-quality plastic polymer that resists both mechanical stress and chemical influences. UV resistance ensures that the gland does not discolour or become brittle even under prolonged exposure to sunlight. Flame retardancy according to UL 94V-0 reduces fire risk in the event of a short circuit or overload.

Compatibility and Accessories
The cable gland is compatible with devices featuring an M25 x 1.5 thread connection. As suitable accessories, a TP connector TP, field-terminated, CAT6A, RJ45, tool-free, is offered. This connector can be directly attached to the cable without requiring additional tools, speeding up installation. The combination of cable gland and RJ45 connector is particularly suitable for network applications where a secure and tight connection is required.

Mounting and Installation
Mounting is done via screw connection to the device or enclosure. Cables are routed through the interior of the gland and secured by the elastic seal. The elongated shape facilitates cable routing and reduces mechanical stress at the cable end.

Advantages in Operation
The cable gland provides a reliable and tight connection that remains effective even under difficult environmental conditions. The high temperature resistance from -40 °C to 105 °C (short-term up to 160 °C) enables use in extreme environments, such as in cooling systems, heating systems, or industrial processes. The UV- and chemical-resistant surface ensures long service life and minimizes maintenance requirements. The tool-free mounting of the compatible RJ45 connector reduces installation time and increases efficiency in network construction.

General
Thread	M25 x 1.5
Norm	EN60423
Material	halogen-free nylon PA 66
Flame retardancy	UL 94V-0
Degree of protection	IP68
Operation temperature	-40 to 105 °C
Short-term temperature	up to 160 °C
Colour	RAL9005 Black
UV resistance

---
