ALLNET point-to-point modem g.fast via 2-wire managed master ALL-BM310 content_copy

ALLNET point-to-point modem g.fast via 2-wire managed master ALL-BM787,4 cm ( 310 inch ) Highlight: G.Fast bridge master modem Integrated splitter for simultaneous operation of analog telephone and g.fast over the same cable. Network via 2 twisted wires in combination with ALL-BM300 slave modem (modem is required separately - please note our ALL-BM320 bundle here. The ALLNET ALL-BM310 is a G.fast master modem, which you can use in combination with a ALL-BM300 in a quick and easy way Network Features: Compliant with IEEE 802.3 / 802.3u / 802.3ab Ethernet Standard Compliant with ITU-T G.9700/G.9701 G.fast standard Support 212a G.fast band profile Support High Bandwidth up to 1Gbps Support USB 3.0 for connecting USB Dongle Support HTTP/HTTPS web management Support remote management and monitor Support configuration backup and restore On board surge protection for Line port Support bridge(switch) ALL-BM310 Master only) Support RJ-11 / Terminal block combo line port Support NTP Time Server. Support TR-069. On board POTS analogue Telephone splitter Support Jumbo frame(MTU) up to 1600 bytes Specifications Standards: IEEE802.3/802.3u/802.3ab standards ITU-T G9700/G9701 standards Interfaces: 4 x RJ-45 10/100/1000 Mbps Ethernet port 1 x RJ-11 / Terminal block combo for line port 1 x RJ-11 connector for POTS analogue phone device 1 x Reset Button for resetting to factory default LED: 1 x Power LED 4 x Link/Active Status for Ethernet port 1 x Link LED for G.fast mode 1 x Link LED for xDSL mode Input Power DC 12V / 2A Powersupply included Dimensions: 196mm x 146mm x 40 mm ( 19,6 cm ( 7,7 inch ) x 5.75 x 1.57”) Net weight: approx. 0.4 kg Temperature 0°~50° C (Operating), -20° ~70° C (Storage) Humidity 10 - 90% non-condensing Marks CE FCC RoHS Compliant Package Contents: 1x ALL-BM310 1x 12V/2A Powersupply included 1x Patchcable 1x RJ11 to RJ11 Cable 1x QIG
