Vertiv (Knürr) SmartAisle?, e.g. Switch 48,3 cm ( 19 inch ) tube, for switch height 7-12U, max. suction area, light gray

* Order-related, cannot be canceled *, Description For applications with and without raised floor Can be used for switches with side cooling for energy-efficient cooling Suction of cooling air from the cold aisle (ideally with enclosure) Suitable for Knürr Miracel® and DCM® cabinet Cabinet width 800 mm Requires 3 or 6 U of the 48,3 cm ( 19 inch ) installation space Suitable for different switch heights Variable height installation of the switches in the cabinet possible INFO: Cold-warm separation in the rack necessary Suitable for CISCO Catalyst 4503(-E), 4506(-E) , 4507R(-E), 4510R(-E) Tube material: Sheet steel Sealing foam: PUR ether foam (UL94 HF-1) Surface Powder-coated, RAL 7035, light gray Scope of delivery 1 suction insert 1 height-adjustable side air duct Sealing foam Mounting material Delivery condition In sets IMPORTANT Suitable for cooling a maximum of 5 kW heat load (at ?T = 13 K) per switch tube. On many switches, part of the front intake perforation is covered (as this is often very far forward behind the front 48,3 cm ( 19 inch ) profiles). May not be usable with switches with different cooling directions. Note Subsequent installation may be difficult due to the existing cabling and accessory components.
