MANHATTAN 102346
Under-Desk Mount Induction Charger 10W Turns your furniture into a charging pad with fast charging function, 10W / 7.5W / 5W output power, black

Invisible wireless charger - turn your table into an induction charging pad
As convenient as wireless charging is, the chargers themselves are unsightly, take up a lot of desk space and are conspicuously useless when inactive . This Manhattan induction charger solves these disadvantages: It hides a wireless charger at the bottom of your desk. There the device remains invisible and your desk is completely free.
Works with many non-metallic surfaces
The included kit makes your non-metallic desk chargeable and is perfect for surfaces such as wood, plastic, glass, marble, ceramic, granite and more. It is also suitable for other furniture such as coffee tables, kitchen worktops, benches or shelves. Do you want a bedside table without clutter of charging cables? This is possible with this, place your phone on it before you go to sleep and it will be fully charged when you wake up. Do you have a restaurant or an employee office? Offer modern charging options on your restaurant tables or office desks.
Maximum convenience for all Qi® compatible devices
This Manhattan induction charging pad offers Qi-compatible fast charging for ;for all smartphones with Qi support. It charges with up to 10 W for cell phones from Samsung®, Google, Asus, Huawei, etc., and 7.5 W for iPhones®. Other devices such as AirPods®, inductive charging cases and smartwatches can also be charged on it.
Safe induction charging with a long range
The surface through which you charge can up to 30 mm thick, which is significantly more than conventional wireless chargers. Mobile phone accessories such as cases or PopSockets® are not an obstacle and do not need to be removed. If you place a metal object such as a key on the loading area, it will be detected and a mechanism will automatically stop loading. Overcharging, over-voltage and overheating protection ensure further safety.
Easy, tool-free installation
Included is an adhesive tape that allows you to attach the charger below your preferred surface. Then simply connect the included power supply and induction charging can begin. Tinkering work such as drilling is not necessary. The charging pad has a deviation tolerance of 20mm, so you don't have to place your device perfectly in the middle to charge it. If you would like to fix the charger more firmly, you can use the four screws provided. To make charging even more efficient, stick the included coil sticker on the surface above the charging pad. - Can be discreetly attached under your table or other non-metallic surface and turns it into an inductive charging pad

• Wireless charger for charging without clutter on coffee tables, office desks, bedside tables, kitchen worktops, shelves, benches and more
• Attaches with adhesive tape or mounting screws, both included
• Wireless quick charging function for compatible devices - cell phones, cases, headphones, smartwatches and more - with up to 10 W output power
• Ideal for catering such as restaurants, hotels and more
• Charging range 15 - 30 mm; Charging point on induction field with 20 mm deviation tolerance
• 10 W fast charging function for Qi-compatible smartphones and 7.5 W fast charging function for Apple® iPhones
• Overcharging, over-voltage and overheating protection
• Foreign Object Detection (FOD) prevents interference and device damage caused by metal objects on the charging pad
• Includes optional coil sticker that can be removed without leaving any residue to mark the charging area and make it more efficient
• Status LEDs for easy overview
• Effective wireless charging also through protective cases and PopSockets®
• 3 year warranty Standards and certificates:
• CE
• RoHS
• FCC
General

• DC power socket input: 24.0 V / 1.0 A
• Charging range: 15 - 30 mm
• Deviation tolerance of charging point on induction field: 20 mm
• Charging efficiency: = 75%
• Watt settings (max.):
• 5.0 W / 7. 5 W / 10.0 W
• Power consumption in standby: < W
Protective measures

• Short Circuit Protection (SCP) with Auto Recovery Mode
• Overvoltage Protection (OVP) with Auto Recovery Mode
• Overcurrent Protection (OCP) — Voltage limit:150% (max)
• Over-temperature Protection (OTP)
• Foreign Object Detection (FOD)
compatibility

• 10W fast charging mode:
• Samsung Galaxy S7 / S7 Edge / S8 / S8+ / S9 / S9+ / S10 or higher
• Huawei Mate20 Pro, Mate20 RS, P20 Pro, P30 Pro or higher
• Samsung Note 8 / 9 / 10 or higher
• 7.5W fast charge mode::
• Apple iPhone 8 / 8 Plus / X / XR / XS / XS Max / 11 / 11 Pro / 11 Pro Max / 12 mini / 12 / 12 Pro / 12 Pro Max
• 5W Mode:
• All other Qi®-enabled devices including Google Pixel and Nexus, smartphones from Asus, LG, Sony and more
Physical details

• Dimensions (L x W x H): 106 x 106 x 20 mm
• Weight: 190 g
• Housing : ABS plastic
Ambient conditions

• Operating temperature: 0 - 40°C
• Storage temperature: -20 - 65°C
• Humidity (non-condensing): 10 - 90%
Scope of delivery

• Induction charger for under-table mounting 10 W
• 3M adhesive tape
• Four mounting screws
• Coil sticker
• DC -Power supply, 24 V / 1 A, 1.2 m cable
• Quick guide Color: Black Product dimensions: 106 (L) x 106 (W) x 20 (H) [mm]
