Helukabel 10008 Helu JZ-500 6G0, 5qmm , PVC control cable 100m ring

Technical data:

Special PVC sheathed cable GN-GE based on DIN VDE 0285-525-2-51 / DIN EN 50525-2-51
Temperature range moving -15°C to +80°C fixed -40°C to +80°C
Nominal voltage U0/U 300/500 V
Test voltage 4000 V
Breakdown voltage min. 8000 V
Insulation resistance min. 20 MOhm x km
Minimum bending radius moving 7.5x cable Ø fixed 4x cable Ø
Radiation resistance up to 80x106 cJ/kg (up to 80 Mrad)
Construction:
Bare copper wire, according to DIN VDE 0295 cl.5, fine-wire, BS 6360 cl.5, IEC 60228 cl.5
Core insulation made of special PVC
Core marking according to DIN VDE 0293 black Cores with continuous white numbering
Cores twisted in layers with optimal lay lengths
Outer jacket made of special PVC
Jacket colour: grey (RAL 7001) with meter marking
Properties:
Largely oil-resistant, oil/chemical resistance
conditionally suitable for drag chains, conditionally suitable for torsion
The materials used in production are free from silicone and cadmium and free from substances that impair paint wetting
Tests:
PVC self-extinguishing and flame-retardant in accordance with DIN VDE 0482-332-1-2, DIN EN 60332-1-2, IEC 60332-1-2 (corresponds to DIN VDE 0472 Part 804 test type B)
Notes:
'Cleanroom qualified\lashshielded analogue types: F-CY-JZ, F-CY-OZ (LiY-CY), Y-CY-JB, Y-CY-JZ
Use:
Used for medium mechanical stress for flexible application with free movement without Tensile stress and without forced movement in dry, damp and wet rooms, but not outdoors, as a measuring, monitoring and control cable on machine tools, assembly lines and conveyor belts, production lines, in plant engineering, in air conditioning technology, in steel and steel rolling mills.
Standard lengths: 100 m, 500 m, 1000 m.
Subject to technical changes.
Type: HELJZ6G0,5
