Rittal 7030111 DK CMC III Temperature/humidity sensor, WHD: 80x28x40 mm
|
-7% 186,08 EUR 199,11 EUR |
|||||||||||
|
( 221,44 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Lieske Part No.: | 464635 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 7030111 | ||||||||||
| UPC/EAN: | 4028177659490 | ||||||||||
| Weight: | 0 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Rittal 7030111:
Benefits: Fast connection and automatic detection via plug & play
Power is supplied via the CAN-BUS interface.
Applications: Monitoring of enclosures in the areas of IT, industry and facility management
Monitoring of enclosures, rooms and containers in the IT environment
Function principle: Settings can be made via the CMC III Processing Unit
The CMC III temperature/humidity sensor monitors the ambient temperature and air humidity in the enclosure.
The sensor has an integrated temperature sensor and an integrated air humidity sensor.
Material: Plastic
Front: Smooth
Enclosure: Textured
Colour: Front: RAL 9005
Enclosure: RAL 7035
Protection category IP to IEC 60 529: IP 30
Supply includes: Sensor
Installation and Short User's Guide
Mounting bracket
Assembly parts
Mounting clips for support rails
Packs of: 1 pc(s).
EAN: 4028177659490
Customs tariff number: 90269000
eCl@ss 5.1: 27189253
eCl@ss 7.0: 27189253
ETIM 6.0: EC002627
Design: Temperature/humidity sensor
Dimensions: Width: 80 mm
Height: 28 mm
Depth: 40 mm
Connection to the CAN bus: Direct
Maximum no. of users: CMC III Processing Unit Compact: 4
CMC III Processing Unit: 32
Operating temperature: Operation (environment): +0°C...+55°C
Ambient humidity (non-condensing): Operation (environment): 5 % - 95 %
Measuring technique: Temperature sensor chip
Humidity sensor chip
Measurement range: Temperature (internal): 0 °C - 55 °C
Temperature (external): 0 °C - 55 °C
Humidity: 5 % - 95 %
Interfaces/connections: General: 2 x RJ45 CAN bus
Weight/pack: 0.16 kg
Type: DK 7030.111
Questions & answers
What is the delivery time of Rittal 7030111 DK CMC III Temperature/humidity sensor, WHD: 80x28x40 mm?
The article Rittal 7030111 DK CMC III Temperature/humidity sensor, WHD: 80x28x40 mm is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 8 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Rittal 7030111 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Rittal 7030111 DK CMC III Temperature/humidity sensor, WHD: 80x28x40 mm always at the best possible price. We can give you a discount of 2% on Rittal 7030111 DK CMC III Temperature/humidity sensor, WHD: 80x28x40 mm if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduation prizes with every purchase. If you buy a minimum of 5 pieces of Rittal 7030111 DK CMC III Temperature/humidity sensor, WHD: 80x28x40 mm we can offer you a price of 183,29 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
