PLANET 24-Port 10/100TX 802.3at PoE + 2-Port Gigabit TP/SFP
|
320,72 EUR |
|
|
( 381,66 EUR incl. VAT ) plus delivery charges |
|
| Delivery time on requestinfo_outline | |
| Lieske Part No.: | 1226127 |
|---|---|
| Mfg Part No: | FGSW-2624HPS4 |
| UPC/EAN: | 4711605281249 |
| Weight: | 0.12 kg |
Product information for Planet FGSW-2624HPS4:
The PLANET FGSW-2624HPS4 is a cost-effective Layer 2 managed PoE+ switch engineered for SMB and industrial PoE deployments. With 24 IEEE 802.3af/at Fast Ethernet PoE+ ports and two Gigabit TP/SFP combo uplinks, it delivers 30 watts per port and a total PoE budget of 370 watts. Ideal for centralized IP surveillance, VoIP, and Wi-Fi deployments, the switch integrates advanced management, security, and energy-saving features.
Advanced PoE Features:
- PD Alive Check for automatic reboot of non-responsive devices
- PoE Port Sequence to stagger PoE activation at boot
- PoE Scheduling to reduce power usage during off-hours
Powerful Layer 2 & Layer 4 Networking:
- VLAN support: port-based, IEEE 802.1Q, Q-in-Q, Voice VLAN
- MSTP/RSTP/STP and link aggregation via LACP or static trunk
- QoS: Layer 2-4 classification, WRR, priority queuing
- IGMP/MLD Snooping for multicast optimization
Comprehensive Security Suite:
- IPv4/IPv6 and MAC-based ACL
- Port-MAC-IP Binding
- DHCP Snooping and ARP Inspection
Flexible Uplink and Long-Distance Fiber Options:
- 2 TP/SFP combo ports (RJ45 or fiber)
- Fiber expansion from 550m to 120km (via SFP modules)
User-Friendly and Secure Management:
- IPv4/IPv6 dual stack
- Web, Telnet, Console, SNMP v1/v2c/v3
- Encrypted access via SSH and SSL
- PLANET Smart Discovery Utility
Technical Specifications:
Ports:
- 24 x 10/100BASE-TX RJ45 with PoE+
- 2 x 10/100/1000BASE-T RJ45 (shared)
- 2 x 1000BASE-X SFP slots (shared with ports 25–26)
- 1 x RJ45 Console port
Switching:
- Architecture: Store-and-Forward
- Switching Capacity: 8.8Gbps
- MAC Address Table: 16K
- Jumbo Frame: 16K Bytes
- Shared Data Buffer: 4Mbit
PoE Capabilities:
- Standard: IEEE 802.3af/at, Mid-span
- Output: 53V DC, up to 30W per port
- Budget: 370W total
- Power Pin Assignment: 4/5 (+), 7/8 (–)
Physical & Environmental:
- Dimensions: 441.2 x 207.5 x 44 mm (1U)
- Weight: 2.79 kg
- Enclosure: Metal, Rack-mountable
- Fans: 2
- Max Power Consumption: 413W / 1409 BTU
- Operating Temp: 0 ~ 50 °C
- Humidity: 10 ~ 90% RH (non-condensing)
Compliance:
- IEEE 802.3af/at, 802.1Q, 802.1D/w/s, 802.1p, 802.3x, LLDP
- RFC: IGMP v1/v2/v3, MLD v1/v2
- Certifications: FCC Class A, CE
