Helukabel 22117 HELU PUrö-JZ 3G0.75qmm gray drag chain cable

Technical data:

Special PUR hose cable based on DIN VDE 0285-525-1 / DIN EN 50525-1
Temperature range moving -20°C to +80°C fixed -40°C to +80°C
Nominal voltage U0/U 300/500 V
Test voltage 4000 V
Breakdown voltage min. 8000 V
Insulation resistance min. 20 MOhm x km
Minimum bending radius moving 7.5x cable Ø fixed 4x cable Ø
Radiation resistance up to 100x106 cJ/kg (up to 100 Mrad)
Structure:
Bare copper wire, according to DIN VDE 0295 cl.5, fine-wire, BS 6360 cl.5, IEC 60228 cl.5
Core insulation made of oil-resistant PVC compound type TI2 based on DIN VDE 0207-363-3 / DIN EN 50363-3, with improved sliding properties
Core identification in accordance with DIN VDE 0293 Black cores with continuous white numbering
Cores stranded in layers with optimal lay lengths
Outer jacket made of special full polyurethane mixture type TMPU in accordance with DIN EN 50363-10-2
Jacket color: gray (RAL 7001) with meter marking
Properties:
resistant to UV rays, oxygen, ozone hydrolysis, microbes
The materials used in production are silicone and cadmium-free and free from substances that impair paint wetting
Notes:
Shielded analogue types: FC-PURö-JZ, Yö-C-PURö-JZ
Use:
Extremely robust control cable, which is characterized by high abrasion resistance and notch toughness. With high-quality oil-resistant PVC core mixture. Due to its resistance to mineral oils, especially to coolant emulsions, it is used in machine, tool and plant construction, in rolling mills and steelworks in particularly critical places. For medium mechanical stress for flexible use with free movement without tensile stress and without forced movement in dry, damp and wet rooms and outdoors. Can be laid quickly and safely due to its good flexibility.
Standard lengths: 100 m, 500 m, 1000 m.
Subject to technical changes.
Type: PUROE-JZ 3X0,75 QMM
