Siemens 3NC32436U, EAN: 4001869521770

Siemens 3NC3243-6U SITOR fuse insert NH3 1250A aR

Installation > Securing material > NH fuses and accessories

Siemens 3NC3243-6U SITOR fuse insert NH3 1250A aR

Lieske Part No. 1283585
Mfg Part No 3NC32436U
EAN-Code 4001869521770
Manufacturer Siemens
Here only 678,30 EUR
807,18 EUR incl. VAT

Further information for Siemens 3NC3243-6U SITOR fuse insert NH3 1250A aR

General
Nominal current1250 A
Operating voltage AC690 V
Operating voltage DC440 V
Fuse typeaR automatically resettable
SizeNH3 -
Modelwith double internal thread -
ApprovalsIEC, UL, partially CCC -
ApplicationSemiconductor protection in frequency converters, UPS systems, soft starters -
Disconnection characteristicsuperflink -
Front indicatorYes -
The Siemens SITOR fuse insert type 3NC3243-6U is a semiconductor protection fuse insert for use in electrical installations, particularly in systems with power semiconductors such as frequency converters, UPS systems or soft starters. It belongs to the SENTRON protection component family and serves to protect personnel, equipment and installations by safely disconnecting in the event of overload or short circuit. The insert is designed for NH3 size and features double internal threading, enabling easy installation in suitable fuse compartments, switch disconnectors or fuse switch disconnectors.

Applications
This fuse insert is specifically designed for the protection of power semiconductors, which are sensitive in the event of short circuits. It is commonly used in installations that include frequency converters with fuses in the input or DC link circuit, as well as in interruption and soft start systems for motors. The application is in industrial and technical electrical installations where high reliability and fast response in the event of a fault are required.

Functions and Equipment in Detail
The SITOR fuse insert 3NC3243-6U offers a super-fast tripping characteristic, enabling a faster response to short circuit events compared to conventional NH fuses. This is crucial to protect power semiconductors from thermal and electrical damage. The characteristic curve accuracy, meaning constant and predictable tripping behavior, is guaranteed by the Siemens quality standard. The insert is equipped with a front indicator, which visually displays the fuse status.

Technology Explained Simply
The fuse is rated for a nominal current of 1250 A and provides protection in alternating and direct current installations. The maximum operating voltage is 690 V for alternating current (AC) and 440 V for direct current (DC). The designation aR (automatically resettable) means that the fuse does not need to be manually reset after a tripping event, but returns to its normal state automatically during operation. The double internal threading allows for easy and secure installation in standard fuse compartments.

Compatibility and Accessories
The fuse insert is compatible with various SENTRON switching devices and fuse compartments designed for NH3 size. It can be used in switch disconnectors with integrated fuses as well as in fuse switch disconnectors. As accessories, additional SITOR fuse inserts are available in various nominal currents and versions, for example with knife contact or also with double internal threading, in nominal currents from 350 A to 1600 A.

Installation and Mounting
Mounting is done via screw connection using the double internal threading into suitable fuse compartments or switch disconnectors. Installation requires no additional tools or components, as the fuse is directly screwed into the designated holders. Correct alignment and secure connection are essential for functional reliability.

Operational Advantages
The super-fast tripping characteristic and high characteristic curve accuracy ensure reliable and predictable protection. Use in semiconductor applications reduces the risk of damage due to short circuits. Integration into SENTRON systems ensures high compatibility and standardization in electrical installations. The fuse is globally applicable, as it is approved according to IEC and UL standards and partially also has CCC approval.

Protection Rating and Approvals
The fuse insert is designed for use in electrical installations operated under the specified voltage and current conditions. Approvals according to IEC and UL, as well as partial CCC approval, enable use in various markets. The fuse is not intended for outdoor use or in explosive environments, as no specific protection rating such as IP67 or Ex is specified.
