ALLNET ANT-24-1T1R-OMNI-8dbi

ALLNET ANT-24-1T1R-OMNI-8dbi

Networks > Wireless Networking > Antennas

ALLNET ANT-24-1T1R-OMNI-8dbi

Lieske Part No.1994143
Mfg Part NoANT-24-1T1R-OMNI-8dbi
EAN-Code
Manufacturer ALLNET
Here only 119,93 EUR
142,72 EUR incl. VAT

Further information for ALLNET ANT-24-1T1R-OMNI-8dbi

Highlights: • WLAN antenna external rigid
• N socket "Female\dlash• Frequency range: 2.4 ~ 2.5 GHz
• Antenna gain: 8 dBi
• VSWR: 2.0 max.
• Impedance: 50 Ohm
• Operating temperature: -20 °C ~ 65 °
• Housing material: GRP, UV protected
• Length: 510 mm
• Ø: 79.5 mm
• Max. wind speed: 216 km/h
• Protection class: IP65
• With wall bracket 90°
  • Antenna distance to the wall: 55 mm
  • Wall mounting footprint: 80 x 60 mm
  • 4 hole mounting dowel
  • • With stainless steel mast mounting kit for pipes up to 55 mm Ø
    You can connect this WLAN antenna to your WLAN device with an N connection to receive and send signals.Package contents • WLAN antenna
    • Stainless steel mast mounting kit
